Fig. 81: Disconnecting Front High-Pressure Fuel Line From Rear High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.

5. Remove the front high-pressure fuel line.

1. Remove the P-clip retaining bolts.

2. Remove the front high-pressure fuel line.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 82: Removing Front High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.

Installation

NOTE:

Replace the fuel line O-ring seals.

NOTE:

Lubricate the fuel line O-ring seals with 5W30 engine oil meeting Ford
specification WSS-M2C153-G or equivalent prior to installation to help seal
and ease the installation.

NOTE:

When tightening the fuel lines a torque wrench adapter must be used with
the torque wrench. The use of a torque wrench adapter will alter the
effective torque of the torque wrench being used. To correct the effective
torque, a torque multiplication conversion must be used; Refer to
TORQUE MULTIPLICATION CONVERSION .



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 83: Installing Front High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 84: Connecting Front High-Pressure Fuel Line To Rear High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.
