Fig. 21: Disconnecting Fuel Tank Front Connections
Courtesy of FORD MOTOR CO.

10. Release the rear EVAP hose clamp and disconnect the hose.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines - F150 Pickup



Fig. 22: Disconnecting Rear EVAP Hose
Courtesy of FORD MOTOR CO.

11. Disconnect the fuel pump electrical connector.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines - F150 Pickup



Fig. 23: Disconnecting Fuel Pump Electrical Connector
Courtesy of FORD MOTOR CO.

12. Position a Hi-Lift Jack under the fuel tank.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines - F150 Pickup



Fig. 24: Positioning Hi-Lift Jack Under Fuel Tank
Courtesy of FORD MOTOR CO.

13. Remove the fuel tank support straps (9092).

1. Remove the bolts.

2. Remove the fuel tank support straps.
