Ford F150 Pickup. Instruction - part 1007

Fig. 51: Disconnecting Lower Radiator Hose From Degas Bottle
Courtesy of FORD MOTOR CO.

4. Remove the degas bottle.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup



Fig. 52: Removing Degas Bottle
Courtesy of FORD MOTOR CO.

5. To install, reverse the removal procedure.

SENDER UNIT - 4.2L

Removal

1. Partially drain the cooling system. For additional information, refer to COOLING SYSTEM

DRAINING, FILLING & BLEEDING .

2. Remove the water temperature indicator sender unit (10884).

1. Disconnect the connector.

2. Remove the water temperature indicator sender unit.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup



Fig. 53: Removing Water Temperature Indicator Sender Unit - 4.2L
Courtesy of FORD MOTOR CO.

Installation

1. To install, reverse the removal procedure.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup



Fig. 54: Installing Water Temperature Indicator Sender Unit - 4.2L
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup
