Ford F150 Pickup. Instruction - part 91

Fig. 15: Removing LH And RH A-Pillar Passenger Assist Handles
Courtesy of FORD MOTOR CO.

CAUTION: Inspect the passenger assist handle brackets for damage. Replace

the brackets as required.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 16: Removing LH And RH Windshield Side Garnish Moldings
Courtesy of FORD MOTOR CO.

19. Remove the LH and RH windshield side garnish moldings.

20. Disconnect the brake pedal position (BPP) switch electrical connector.

z

Release the wiring harness locators.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 17: Disconnecting Brake Pedal Position Switch Electrical Connector
Courtesy of FORD MOTOR CO.

21. If equipped, disconnect the adjustable pedal motor electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 18: Disconnecting Adjustable Pedal Motor Electrical Connector
Courtesy of FORD MOTOR CO.

22. If equipped, disconnect the adjustable pedal motor harness electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup
