Ford F150 Pickup. Instruction - part 35

Fig. 38: Removing Speed Control Cable Cap
Courtesy of FORD MOTOR CO.

2. Disconnect the speed control cable from the speed control servo.

1. Gently push the retaining spring.

2. Disconnect the speed control cable slug from the speed control servo pulley.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Vehicle Speed Control - F150 Pickup



Fig. 39: Disconnecting Speed Control Cable Slug From Speed Control Servo Pulley
Courtesy of FORD MOTOR CO.

3. Disconnect the speed control servo electrical connector.

z

Depress the connector tabs.

z

Remove the connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Vehicle Speed Control - F150 Pickup



Fig. 40: Disconnecting Speed Control Servo Electrical Connector
Courtesy of FORD MOTOR CO.

NOTE:

Do not remove the rubber grommets from the speed control servo
bracket.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Vehicle Speed Control - F150 Pickup



Fig. 41: Removing Bolts Of Speed Control Servo
Courtesy of FORD MOTOR CO.

4. Remove the bolts, the speed control servo and bracket.

5. Remove the screws and the speed control servo bracket.
