Electric System EL-17 Instrument Panel Technical parameter and function Technical parameter Constitution and function The instrument panel assembly is consisted by speedometer, tachometer, water temperature meter, fuel meter, warning system (14 warning indicator), and matched with the sensor and warner. Disassembly Speedometer (km/h) 0~140 Tachometer (r/min) 0~5000 Fuel meter 0-1/2-1 Water temperature meter ( ℃ ) 40-80-100-120 Nominal voltage (V) 24 1.Panel assembly 9.Speedometer lighting bulb holder 16.Electronic tachometer |
