Vehicle Inspection

7—3

filler of engine until the oil level is up to H
mark. If it is above H mark, the  surplus  oil
must be released from the oil-pan plug  of
the engine.

Note:
If the oil level of engine is lower than required,

the engine will be burnt.

2.Check the remaining fuel

The capacity of the fuel tank is 120L,

and the max continuous running distance
is 500Km. Please check the remaining fuel
before driving and decide whether you
have to fill the tank according to the driving
distance of that very day.

3.Check the brake pipes to see whether  it
is leaky

4.Check the bolts and nuts of steering
system

5.Check  the  front  and  the  rear  leaf  spring
and their bolts and nuts

6.Check the tyre pressure

7.Check the electrolyte height of battery

8.Check the harness(whether is worn by
other parts) and earthing

9.Check each gauge

The needle of the engine  oil  pressure

gauge should be in normal range.  If  the
warning light is lighted for more than  15
seconds, the engine should be shut down
immediately.

The needle of the fuel gauge should

be between E and F.

Vehicle Inspection

7—4

The needle of the

water

temperature gauge should be within
the range inside the inner line on the
scale.

Whether the speedometer works

normally.

Whether the engine fault indicator

is off.

10.Check the horn

Press the horn button and make

sure the horn sounds normally.

11.Check the windshield wiper  and
washer

Clean the windshield  before  the

inspection, and then spray  the  washer
fluid and check  whether  it  is  operated
normally.  Also make sure that the
wipers operate normally in every
speed.

Vehicle Inspection

7—5

12.

Check the front and the rear lamps

1. Headlamp
2. Front fog lamp
3. Front lamp
4. Turning signal lamp
5. Rear clearance lamp
6. Front clearance lamp

7. Side clearance marker
8. Tail combined lamps (rear turning

signal lamp, tail lamp, brake



lamp, rear fog lamp, reversing
lamp)

9. Licence lamp

Make sure that every light is on

when each light switch is connected. It
is more convenient to do this inspection
by two persons.

13.Check the engine,  steering  system,
transmission and rear axle  to  see
whether there is any leakage.

14.Check the steering wheel for free
turning and axial play

With the front wheel set for









movement straight ahead,  alight  rotate
the steering wheel clockwise and







counterwise to check the play.

Vehicle Inspection

7—6

Move the steering wheel in the

axial and radial directions.  There
should be no excessive free play.

15.The exhaust gas inspection

Thoroughly warm up the engine,

and check the color of the exhaust gas
in  order  to  determine  the  condition  of
the engine.

Colorless or light blue: Normal
Black:

Abnormal, incomplete



combustion.

White:  Engine oil is also burning.

However,  exhaust gas are often white
when either air or engine temperature
is low.

Also check the engine operating

sounds and vibrations for any







abnormalty.

16.Check the brake.

Depress the brake pedal while







driving,  and  make  sure  the  braking
response is normal.

17.Check the steering system

During the test running, make sure

that the steering wheel operates







normally without shimming,  difficult
steering or pulling to one side.

10.Checking after test running.

After test running, parking and then

walk around the vehicle to  check  for
any signs of water and air leakage.
