• When Monitored: • Set Condition: Possible Causes (R56) PASSENGER SEAT BELT TENSIONER LINE 1 CIRCUIT OR (R54) PASSENGER SEAT BELT TENSIONER PASSENGER SEAT BELT PRETENSIONER ORC Diagnostic Test 1. DETERMINE ACTIVE OR STORED DTC NOTE: Ensure that the battery is fully charged. NOTE: The scan tool, SRS Airbag Load Tool MRL 8443, and DVOM are required to perform the following Select ACTIVE or STORED DTC: ACTIVE DTC Go To 2 STORED DTC Go To 5 2. CHECK FOR OPEN PASSENGER SEAT BELT PRETENSIONER WARNING: To avoid personal injury or death, turn the ignition off, NOTE: Check connectors - Clean and repair as necessary. WARNING: To avoid personal injury or death, turn the ignition on, Does the scan tool display: B1B2E 1st ROW PASSENGER Yes >> Go To 3 No >> Replace the Passenger Seat Belt Pretensioner in accor- dance with the Service Information. Perform AIRBAG SYSTEM VERIFICATION TEST - VER 1. PM RESTRAINTS - ELECTRICAL DIAGNOSTICS 8O - 121 |
