7. Install timing chain tensioner (1) and torque bolts to
12 N·m (105 in. lbs.).
NOTE: Keep the slack in the timing chain on the
tensioner side.
8. Install the moveable timing chain pivot guide (6)
and torque bolt to 12 N·m (105 in. lbs.).
9. Remove timing tensioner pin 8514 (2).
10. Rotate the crankshaft CLOCKWISE two complete
revolutions until the crankshaft is repositioned at
the TDC position. Verify that the camshaft and
crankshaft timing marks are in proper position.
11. Install front timing chain cover (Refer to 9 -
ENGINE/VALVE TIMING/TIMING BELT / CHAIN
COVER(S) - INSTALLATION).
12. Connect negative battery cable.
13. Fill with oil, start engine and check for leaks.
