Fig. 7: Identifying Dampener
Courtesy of CHRYSLER LLC

5. Remove the dampener (1) from the rear case.

1 - DAMPENER



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP140 - Service Information - Nitro



Fig. 8: Removing/Installing Rear Housing Bolts
Courtesy of CHRYSLER LLC

6. Support transfer case so rear case is facing upward and the input gear is not contacting the work surface.

7. Remove bolts (2) holding front case to rear case (1).

1 - REAR HOUSING
2 - BOLTS
3 - FRONT HOUSING



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP140 - Service Information - Nitro



Fig. 9: Removing/Installing Rear & Front Housing
Courtesy of CHRYSLER LLC

8. Loosen rear case with a case splitter or suitable tool to break sealer bead. Insert case splitter or suitable

tool only into notches provided at each end of case.

9. Remove rear case (1) from front case (2).

1 - REAR HOUSING
2 - FRONT HOUSING

NOTE:

Be careful not to damage the front and rear case sealing surfaces.



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP140 - Service Information - Nitro



Fig. 10: Identifying Front Output Shaft & Retaining Ring
Courtesy of CHRYSLER LLC

10. Remove mainshaft drive sprocket retaining ring.

11. Remove front output shaft drive sprocket retaining ring (2) from the front output shaft (1). See Fig. 10.

1 - FRONT OUTPUT SHAFT
2 - RETAINING RING



2007 Dodge Nitro R/T

2007 TRANSFER CASE MP140 - Service Information - Nitro
