Dodge Nitro. Manual - part 920

Courtesy of CHRYSLER LLC

Fig. 15: LCA Bushing - 9334
Courtesy of CHRYSLER LLC

Fig. 16: LCA Bushing - 9603
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro



Fig. 17: LCA Bushing - 9969
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro



Fig. 18: Remover, Ball Stud 9360
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro



Fig. 19: Puller - 8677
Courtesy of CHRYSLER LLC

BUSHINGS

REMOVAL

BUSHINGS-CLEVIS BRACKET

1. Remove the tire and wheel assembly.

2. Remove the disc brake rotor. Refer to REMOVAL .

3. Remove the wheel speed sensor. Refer to REMOVAL .

4. Remove the lower stabilizer link at the lower control arm.

5. Remove the lower clevis bolt at the control arm.



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro
