Dodge Nitro. Manual - part 885

Fig. 12: Identifying Solenoid Nut, Mounting Stud, Electrical Connector & Battery Cable Assembly
Courtesy of CHRYSLER LLC

5. Remove solenoid nut (1) from mounting stud (3).

6. After nut (1) has been removed, pull battery cable from mounting stud (3) while removing electrical

connector (5) from solenoid terminal.

Fig. 13: Starter Motor - 3.7L
Courtesy of CHRYSLER LLC

7. Remove two starter mounting bolts (1).

8. Remove starter assembly (2) from transmission.

9. Rotate starter assembly to allow removal from vehicle.



2007 Dodge Nitro R/T

2007 ENGINE Starting - Service Information - Nitro



REMOVAL - 4.0L

Fig. 14: Identifying Solenoid Nut, Mounting Stud, Electrical Connector & Battery Cable Assembly
Courtesy of CHRYSLER LLC

1. Disconnect and isolate negative battery cable.

2. Raise and support vehicle.

3. Four Wheel Drive Equipped: Remove front propeller shaft.

4. Remove solenoid nut (1) from mounting stud (3).

5. After nut (1) has been removed, pull battery cable from mounting stud (3) while removing electrical

connector (5) from solenoid terminal.

Fig. 15: Starter Motor - 4.0L



2007 Dodge Nitro R/T

2007 ENGINE Starting - Service Information - Nitro



Courtesy of CHRYSLER LLC

6. Remove two starter mounting bolts (2).

7. Remove starter assembly (1) from transmission.

8. Remove plate (3) from transmission.

9. Rotate starter assembly (1) to allow removal from vehicle.

INSTALLATION

INSTALLATION - 4.0L

Fig. 16: Starter Motor - 4.0L
Courtesy of CHRYSLER LLC

1. Rotate starter assembly (1) to allow positioning into transmission.

2. Install two starter mounting bolts (2) and tighten. Refer to Torque Specifications.



2007 Dodge Nitro R/T

2007 ENGINE Starting - Service Information - Nitro



Fig. 17: Identifying Solenoid Nut, Mounting Stud, Electrical Connector & Battery Cable Assembly
Courtesy of CHRYSLER LLC

3. Position battery cable assembly (2) onto stud (3) while pushing solenoid connector (5) onto solenoid

terminal.

4. Install nut (1) and tighten. Refer to Torque Specifications.

5. Four Wheel Drive Equipped: Install front propeller shaft.

6. Lower vehicle.

7. Connect negative battery cable.

INSTALLATION - 2.8L DIESEL

Fig. 18: Starter Motor - 2.8L Diesel Auto. Trans.



2007 Dodge Nitro R/T

2007 ENGINE Starting - Service Information - Nitro
