Fig. 105: Identifying Input Shaft Retainer Bolts & Retainer
Courtesy of CHRYSLER LLC

4. Install input shaft retainer (1) and tighten bolts (2) to 9 N.m (80 in. lbs.).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 106: Identifying Countershaft Bearing & Bearing Retainer Lip
Courtesy of CHRYSLER LLC

5. Install countershaft bearing (1) into housing with bearing retainer lip (2) facing up.



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 107: Identifying Countershaft Bearing & Retainers
Courtesy of CHRYSLER LLC

6. Install countershaft bearing (1) retainers (2) and tighten bolts to 10 N.m (88 in. lbs.).

FINAL ASSEMBLY



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 108: Installing Mainshaft Onto Build Fixture 9633
Courtesy of CHRYSLER LLC

1. Install mainshaft (1) onto Build Fixture 9633 (2).
