Fig. 130: Remover/Installer 9958
Courtesy of CHRYSLER LLC

Fig. 131: Adapters 9959



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Courtesy of CHRYSLER LLC

COVER-DIFFERENTIAL

REMOVAL

COVER-DIFFERENTIAL

Fig. 132: Identifying Differential Housing & Drain Plug
Courtesy of CHRYSLER LLC

1. With vehicle in neutral, position vehicle on hoist.

2. Remove skid plate.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



3. Remove drain plug (2) from housing (3) and drain fluid.

Fig. 133: Identifying Oil Filter Drain Tray & Vent Hose
Courtesy of CHRYSLER LLC

4. Remove oil filter drain tray (1) and vent hose from differential cover.

Fig. 134: Identifying Front Axle Bracket Cradle Nut & Front Axle Bracket Bolts
Courtesy of CHRYSLER LLC

5. Loosen front axle bracket bolt (1).

6. Remove front axle bracket bolts (2) from the axle and let bracket hang forward of the axle.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



7. Remove differential cover bolts and remove cover.

INSTALLATION

COVER-DIFFERENTIAL

Fig. 135: Applying Bead Of Mopar Axle RTV Sealant To Differential Cover
Courtesy of CHRYSLER LLC

1. Clean cover and mating surface.

2. Apply a bead of Mopar Axle RTV sealant (1) or equivalent to the differential cover (2).

CAUTION: If cover is not installed within 3 to 5 minutes, the cover must be

cleaned and new RTV applied. Failure to follow these instructions will
result in a leak.
