Fig. 64: Identifying Half Shaft & Knuckle
Courtesy of CHRYSLER LLC

10. Pull out on the steering knuckles (2) and push the half shaft (1) out of the knuckles.

11. With a pry bar remove the half shafts (1) from the axle.

Fig. 65: Identifying Oil Filter Drain Tray & Vent Hose
Courtesy of CHRYSLER LLC

12. Remove oil filter drain tray (1) and vent hose (2) from differential cover.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 66: Identifying Front Axle Bracket Cradle Nut & Front Axle Bracket Bolts
Courtesy of CHRYSLER LLC

13. Support axle with a lift/jack.

14. Remove front axle bracket nut and bolt (1) from crossmember. Remove front axle bracket nuts and bolts

(2) from axle housing and remove bracket.

Fig. 67: Identifying Nut/Bolt & Right Axle
Courtesy of CHRYSLER LLC

15. Remove nut and bolt (1) from right axle (2) bracket.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 68: Identifying Bolts & Rear Axle Bracket
Courtesy of CHRYSLER LLC

16. Remove bolts (1) from rear axle bracket (2).

17. Lower axle and from vehicle.

INSTALLATION

FRONT AXLE - 186FIA

Fig. 69: Identifying Bolts & Rear Axle Bracket
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



1. Lift axle into vehicle.

2. Install bolts (1) in rear axle bracket (1) and tighten to 88 N.m (65 ft. lbs.).

Fig. 70: Identifying Nut/Bolt & Right Axle
Courtesy of CHRYSLER LLC

3. Install bolt (1) and nut in right axle (2) bracket and tighten to 61 N.m (45 ft. lbs.).

Fig. 71: Identifying Oil Filter Drain Tray & Vent Hose
Courtesy of CHRYSLER LLC

4. Install oil filter drain tray (1) and vent hose (2) on differential cover.
