Fig. 57: Identifying Differential Housing & Drain Plug
Courtesy of CHRYSLER LLC

1. With vehicle in neutral, position vehicle on hoist.

2. Remove skid plate.

3. Remove differential housing (3) drain plug (2) and drain fluid.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 58: Identifying Front Propeller Shaft Flange & Axle Flange
Courtesy of CHRYSLER LLC

4. Mark front propeller shaft (1) and pinion flange (2) for installation reference. Remove propeller shaft

from pinion flange.

Fig. 59: Identifying Hub Nut & Half Shaft
Courtesy of CHRYSLER LLC

5. Remove hub nuts (1) from half shafts (2).



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 60: Identifying Stabilizer Bar Link & Bolts
Courtesy of CHRYSLER LLC

6. Remove stabilizer bar link (1) bolts (2) from lower control arm.

Fig. 61: Identifying Shocks Clevis & Nuts
Courtesy of CHRYSLER LLC

7. Remove shocks clevis (1) nut (2) and bolt.



2007 Dodge Nitro R/T

2007 DRIVELINE Differential & Driveline - Nitro



Fig. 62: Identifying Tie Rod End & Steering Knuckle
Courtesy of CHRYSLER LLC

8. Remove tie rod end (1) nuts and separate ends from the steering knuckles (2).

Fig. 63: Identifying Upper Ball Joint Nuts & Steering Knuckles
Courtesy of CHRYSLER LLC

9. Remove upper ball joint nuts (1) from steering knuckles (2) and separate ball joints from steering

knuckles (2).
