Fig. 5: Release Tool 8875A
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE Cooling - Nitro



Fig. 6: Adapter Pins 8346
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE Cooling - Nitro



Fig. 7: Spanner Wrench 6958
Courtesy of CHRYSLER LLC

Fig. 8: Cooling System Pressure Tester - 7700A
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE Cooling - Nitro



Fig. 9: Coolant Refractometer - 8286
Courtesy of CHRYSLER LLC

ACCESSORY DRIVE

BELT-ACCESSORY DRIVE

DESCRIPTION

DESCRIPTION

The accessory drive belt is a serpentine type belt. Satisfactory performance of these belts depends on belt
condition and proper belt tension.

DIAGNOSIS AND TESTING

ACCESSORY DRIVE BELT
