Fig. 136: Carrier & Interior Handle
Courtesy of CHRYSLER LLC

14. Remove the interior lock rod from the interior handle.

Fig. 137: Removing/Installing Interior Handle Lock Rod And Grommet
Courtesy of CHRYSLER LLC

15. Remove the interior handle lock rod and grommet from the carrier.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 138: Disconnecting/Connecting Latch Electrical Connector
Courtesy of CHRYSLER LLC

16. Disconnect the latch electrical connector.

Fig. 139: Carrier Plate Slots
Courtesy of CHRYSLER LLC

17. Turn the carrier plate over and slide the latch bracket assembly to remove from the carrier plate slots (1).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 140: Push Pin, Handle & Spring
Courtesy of CHRYSLER LLC

18. Remove the push pin (1) from the handle.

19. Remove the spring (3) and handle (2) from the carrier.

Fig. 141: Disconnecting/Connecting Speaker Electrical Connector
Courtesy of CHRYSLER LLC

20. Disconnect the speaker electrical connector.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 142: Removing/Installing Speaker Bolts & Speaker
Courtesy of CHRYSLER LLC

21. Remove the speaker bolts and speaker from the carrier.

Fig. 143: Carrier Plate Electrical Harnesses & Motor Connectors
Courtesy of CHRYSLER LLC

22. Remove the electrical harness (1) from the carrier plate.

23. Release harness from all the hooks in the carrier plate.

24. Disconnect the connector (2) from the motor.

25. Remove the electrical harness (3) from the carrier plate.

26. Remove the harness from the carrier plate.
