14. Connect the heater hose.

15. Install the right intake manifold support braces.

Fig. 33: Flex Plate Inspection Cover & Fastener
Courtesy of CHRYSLER LLC

16. Install the torque converter inspection plate (1). Tighten bolts to 12 N.m (105 lbs. in.)

17. Install the upper intake manifold (Refer to INSTALLATION ).

18. Connect the upper radiator hose.

Fig. 34: CKP/Oxygen Sensors
Courtesy of CHRYSLER LLC



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



19. Install the crankshaft position sensor (2) (Refer to INSTALLATION ).

20. Connect the engine block heater (if equipped).

Fig. 35: Removing/Installing Oil Cooler & Coolant Hoses
Courtesy of CHRYSLER LLC

21. Connect the oil cooler hose (2) at the cooler.

Fig. 36: Engine Oil Cooler, Coolant Hose, Filter & Lower Radiator Hose
Courtesy of CHRYSLER LLC

22. Connect the oil cooler hose (3) at the cooler.

23. Connect the lower radiator hose (5).



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 37: Installing Starter And Spacer Plate
Courtesy of CHRYSLER LLC

24. Install new oil filter.

25. Install the starter (1) and spacer plate (Refer to INSTALLATION ).

Fig. 38: Removing/Installing Exhaust Pipe
Courtesy of CHRYSLER LLC

26. Connect the left (1) and right exhaust pipe to the exhaust manifold (2).



2007 Dodge Nitro R/T

2007 ENGINE 4.0L - Service Information - Nitro



Fig. 39: CKP/Oxygen Sensors
Courtesy of CHRYSLER LLC

27. Connect the oxygen sensors (1).

Fig. 40: Connecting Generator Electrical Connectors
Courtesy of CHRYSLER LLC

28. Connect the generator electrical connectors (2) (Refer to INSTALLATION ).

29. Fill the cooling system to the proper level using the appropriate coolant.

30. Fill engine crankcase with proper oil to correct level (Refer to FLUID TYPES ).
