AUTOMATIC TRANSMISSION  5A-3

CLUTCH PACK DETAILS

C1

Composition

Steel

C2

Composition

Steel

C3

Composition

Steel

C4

Composition

Steel

0574-000002

5

5(2)

5

4(2)

4

4(2)

3

4(1)

0574-000001, 0574-000004,

0574-000005

4

6(2)

4

5(2)

3

5(2)

3

4(1)

Note : Numbers in brackets indicate number of selective thickness steel plates required to achieve specifed

 clutch pack clearance

5A-4  AUTOMATIC TRANSMISSION

SPECIAL TOOLS

SPECIAL TOOLS TABLE

Part Number

0555 - 332083

0555 - 336046

0555 - 336256

0555 - 336257

0555 - 336258

0555 - 336259

0555 - 336260

0555 - 336261

0555 - 336262

0555 - 336263

0555 - 336264

0555 - 336265

0555 - 336266

0555 - 336267

0555 - 336268

0555 - 336269

0555 - 336270

0555 - 332895

Description

Solenoid / Thermistor, Electronic Tester

Solenoid, Bench Tester

Transmission Bench Cradle

Pump Puller

Pin Remover / Installer Tool (Cross Shaft / Detent Lever)

Clutch Spring Compressor

Clutch Pack Clearance Kit

Seal Removal Tool (Cross - Shaft)

Oil Seal Dolly (Cross - Shaft)

Assembly Bullet

Seal Compressor

Pin Press

Seal Dolly

Alignment Tool

Pump Seal Dolly

End Float Adaptor

End Float Shaft

Locknut Crimping Tool (W-Car Only)

AUTOMATIC TRANSMISSION  5A-5

SCHEMATIC AND ROUTING DIAGRAMS

TCU CIRCUIT (4WD-DIESEL)

5A-6  AUTOMATIC TRANSMISSION

TCU CIRCUIT (4WD-GASOLINE)
