7-1

Cleaning

PE ENGINE COOLING SYSTEM

CF65/75/85 series

2

6

7. CLEANING

7.1 CLEANING THE EXTERIOR OF RADIATOR/AIR COOLER

}

Inhalation of dust may have serious

consequences for your health. Take

the necessary precautions, such as

wearing goggles and a face mask.

Cleaning wire mesh
1.

Remove the lower grille.

2.

Remove the wire mesh.

3.

Clean the wire mesh.

Cleaning, radiator/air cooler
With the aid of a simple tool, the radiator and the

air cooler can be blow-cleaned.

This tool can be made in your own workshop. It

cannot be ordered from DAF.

Key to drawing:

1.

Solder up

2.

Solder

3.

Quick-release coupling for air hose

4.

Steel pipe, ø 10 mm

5.

6 x ø 1.5 mm between holes, with a centre-

to-centre distance between the holes of 7

mm, drilled on one side.

Note:

Make sure that the air cooler and radiator

element are not damaged when positioning the

radiator cleaner.

1.

From below, insert the radiator cleaner (4)

between the air cooler (1) and radiator (2),

with the air holes facing the air cooler (1).

2.

Apply air pressure to the radiator cleaner (4)

and continue blow-cleaning the air cooler (1)

until no more dirt comes out.

100mm

5mm

2

1150mm

2

4

3

5

5

4

1

1

M2108

1

2

3

4

M2109

P

PE ENGINE COOLING SYSTEM

7-2

©

 200324

Cleaning

6

CF65/75/85 series

2

3.

Turn the radiator cleaner over, turning the

holes towards the radiator (2), and blow-

clean the radiator (2).

4.

Fit the wire mesh.

5.

Install the lower grille.

1

2

3

4

M2110

P

©

 200324

7-3

Cleaning

PE ENGINE COOLING SYSTEM

CF65/75/85 series

2

6

7.2 FLUSHING COOLING SYSTEM

}

In order to avoid damaging the

cylinder block, do not top up a warm

engine with cold coolant. Coolant is

a toxic fluid and must be handled

with care. Protect skin and eyes.

Coolant is harmful to the

environment; after use, it should be

processed as industrial chemical

waste. When the coolant is hot, there

is overpressure in the cooling

system. When removing the filler

cap, allow the overpressure to

escape by first loosening the filler

cap one turn.

1.

Drain the cooling system at the cylinder

block via the drain tap (A), the radiator via

drain plug B and the oil cooler via plug C. If

an integrated retarder is fitted, remove the

coolant drain plug of the heat exchanger.

2.

Flush the cooling system.

3.

Close the drain cock (A) and fit drain plug B

and, if applicable, the coolant drain plug of

the heat exchanger of the integrated

retarder.

4.

Fill the cooling system.

5.

Check the coolant level.

M2097

A

B

C

G000182

B
