DAF CF65, CF75, CF85 Series . Manual - part 180

©

 200351

7-7

XE engine

TECHNICAL DATA

ΧΦ65/75/85 series

2

0

Cylinder head attachment bolts
Cylinder head bolts must only be used once. So
the cylinder head bolts must always be replaced.
The thread of the new cylinder head bolts is
provided with a red/brown sealant.

Note:
-

Due to the sealant used on the cylinder head
bolts, the untightening torque of the cylinder
head bolts can be substantial!

-

All M16 and M12 threaded holes must be
carefully cleaned using a screw tap prior to
the mounting of the bolts.

-

After tightening of the bolts with the
appropriate tightening torque, the angular
displacement of the M16 bolts must
immediately be started.

-

The sealant cannot be applied later.

M16

50 Nm

I

60

M12

II

III

III

M16

M200563

M16

150 Nm

II

94 Nm

60

M16

TECHNICAL DATA

7-8

©

 200351

XE engine

0

ΧΦ65/75/85 series

2

Tightening cylinder head attachment bolts

Note:
Underneath the bolt head, apply a drop of oil on
the bearing surface of the bolt heads. Sealants
also reduce the frictional resistance, which
means that you must not apply any oil to the
thread.

(1) Apply a drop of oil to the bearing surface of the M16 and

M12 bolt heads.

Timing gear

(1) Use Loctite 243 to secure
(2) Apply a drop of oil to the attachment bolts and tighten

evenly.

M200562

16

15

10

5

4

3

9

14

13

12

8

2

1

7

11

17

6

21

18

19

20

1

st

 phase

- M16 in the indicated
order

50 Nm

(1)

2

nd

 phase

- M16 in the indicated
order

150 Nm

- M12 in the indicated
order

94 Nm

(1)

3

rd

 phase

- M16 in the indicated
order in two stages of

60

 angular

displacement

Pump housing drive unit attachment bolts

60 Nm

Attachment bolts, pump housing drive shaft
locking plate

30 Nm

(1)

Locking plate attachment bolts

30 Nm

(1)

Crankshaft hub attachment bolts in 4 phases:
1

st

 phase, all attachment bolts

100 Nm

(2)

2

nd

 phase, all attachment bolts

100 Nm

(2)

3

rd

 phase, all attachment bolts

100 Nm

(2)

4

th

 phase, all attachment bolts

100 Nm

(2)

Viscous fan clutch attachment nuts

30 Nm

(1)

Timing case attachment bolts

30 Nm

(1)

Timing cover attachment bolts:
- M10 attachment bolts

60 Nm

- M8 attachment bolts

25 Nm

Timing cover protection plate attachment bolt

8.5 Nm

Camshaft gear attachment bolt

425 Nm

Idler gear attachment bolt

170 Nm

Pump housing camshaft gear attachment bolt

260 Nm

(1)

Steering pump gear attachment nut

80 Nm

(1)

Suction pipe banjo bolt

90 Nm

Delivery pipe banjo bolt

40 Nm

©

 200351

7-9

XE engine

TECHNICAL DATA

ΧΦ65/75/85 series

2

0

Flywheel housing

(1) Use Loctite 243 to secure

Flywheel

Engine mountings at timing gear end

Engine mountings at flywheel end

Engine hanger brackets

Valve gear

Tighten the valve sleeve attachment bolts in the
sequence shown

Attachment bolts

110 Nm

(1)

Sealant to be used when fitting flywheel housing

Loctite 510

Attachment bolt, crankshaft sensor

8 Nm

Attachment bolts:
- standard

260 Nm + 60

 angle tightening

- with engine PTO

260 Nm + 120

 angle tightening

Cylinder block bracket attachment bolts

110 Nm

Chassis engine bracket attachment bolts

110 Nm

Vibration damper engine bracket attachment
bolts

170 Nm

Flywheel housing engine bracket attachment
bolts

260 Nm

Chassis engine bracket attachment bolts

110 Nm

Vibration damper engine bracket attachment
bolts

260 Nm + 90

 angle tightening

Attachment bolts:

110 Nm

Valve cover attachment bolts

25 Nm

Rocker setting bolt lock nut

40 Nm

Bridge piece setting bolt lock nut

40 Nm

Lubricating oil strip/rocker seat attachment bolts

110 Nm

DEB set screw nut

25 Nm

Solenoid valve

20 Nm

Wiring harness attachment bolt

9 Nm

Valve sleeve attachment bolts

30 Nm

1

5

2

6

4

12

10

13

9

15

7

11

8

14

3

M200942
