DAF CF65, CF75, CF85 Series . Manual - part 1231

©

 200419

67

ENGINE



2

2

1329370

Valve stem seal driving tool

1329382

Pressure punch for fitting 1st bearing on fan drive shaft

1329383

Pressure punch for fitting 1st bearing ring in fan drive

bearing housing

1329384

Pressure punch for fitting 2nd bearing ring in fan drive

bearing housing

1329370

1329382

1329383

1329384

ENGINE

68

©

 200419

2

2

1329385

Driving tool for fitting oil seal in fan drive bearing housing

1329386

Pressure punch for fitting 2nd bearing on fan drive shaft

1329394

Oil cooler pressure-test plate

1329395

Oil cooler pressure-test plate

1329385

1329386

1329394

1329395

©

 200419

69

ENGINE



2

2

1329402

Press for fitting rear crankshaft seal

1329420

Valve seat pressure punch

1329421

Valve seat pressure punch

1329423

Disassembly of camshaft bearings

1329402

1329420

1329421

M201372

ENGINE

70

©

 200419

2

2

1329429

Valve guide press-out tool

1329430

Exhaust valve guide die set

1329431

Inlet valve guide die set

1329436

Upspeed fan bearing installer

1329429

1329430

1329431

1329436
