 200423

4-19

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

4.13 REMOVAL AND INSTALLATION, WHEEL HUB

FTP leading rear axle

Removing the wheel hub

1.

Remove the hub cover (1) using special tool
(DAF no. 1329498)

2.

Lift the leading rear axle and support it
properly.

3.

Remove the split pin (2) and the hub nut (3).

4.

Remove the outer wheel bearing (4).

5.

Remove the hub (6) with the wheel.

Installing the wheel hub
1.

Apply new grease to the hub (6).

2.

Install the hub with the wheel.

3.

Fit the outer wheel bearing (4).

4.

Fit the hub nut (3).

5.

Adjust the wheel bearing play, see chapter
"Inspection and adjustment".

6.

Fit the split pin (2).

7.

Lower the leading rear axle.

8.

Fit the hub cover using special tool
(DAF no. 1329498). Tighten the hub cover to
the specified torque, see main group
"Technical data".

9.

Adjust the brakes.

1

2

4

5

6

7

8

9

10

3

S7 00 640

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-20

©

 200423

Removal and installation

5

ΧΦ85 series

©

 200423

5-1

Draining and filling

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

5. DRAINING AND FILLING

5.1 TOPPING UP BATTERY FLUID

Avoid sparks and open flames in the
vicinity of batteries.
Battery acid is an aggressive fluid.
In the event of contact with the skin:
rinse the skin with plenty of water for
a sustained period. If redness or
pain persists, consult a doctor.
Remove any clothing affected and
rinse with water.
In the event of contact with the eyes:
rinse with plenty of water for at least
15 minutes and consult a doctor.
If swallowed: do NOT induce
vomiting. Rinse the mouth, drink two
glasses of water and consult a
doctor.
In the event of inhalation: get fresh
air, rest and consult a doctor.

Topping up battery fluid
1.

Clean the top of the battery. If the top of the
battery has acid on it, it should be rinsed with
water.

2.

Remove the plugs and top up the batteries
with distilled water to approximately 10mm
above the plates or up to the "max" indicator
level.

Engine, cooling system and fuel system

}

M5011

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

5-2

©

 200423

Draining and filling

5

ΧΦ85 series

5.2 DRAINING AND FILLING THE ENGINE OIL

To prevent skin injury, avoid
unnecessary contact with the
drained oil

Draining the engine oil
1.

Ensure that the vehicle is standing on a flat
and level surface.

2.

Drain the engine oil at operating temperature
using the drain plug in the oil sump.

3.

Replace the drain plug sealing ring and
tighten the drain plug to the specified torque,
see "Technical data".

Filling the engine oil
1.

Through the oil filler pipe (D), fill the engine
with the specified amount of engine oil , see
"Technical data".

2.

Check the engine oil level, see "Inspection
and adjustment".

}

V300389

D
