DAF CF65, CF75, CF85 Series . Manual - part 1190

©

 200423

2-3

General

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

2.4 ENVIRONMENT

By carrying out the maintenance activities in a
professional manner, on time and at regular
intervals, you will help to reduce the impact on the
environment.
This means, for example, noticing and remedying
possible leakages in time and keeping the engine
in an optimum condition (adjusting valves,
replacing air filter element etc.), thus reducing the
emission of harmful exhaust gasses.
It should be noted that oils and fluids contain
harmful substances that have a negative impact
on the environment.
That is why you should take care that drained oils
and fluids and also discarded oil and fuel filters,
are collected in separate receptacles or
containers.
In short: maintenance activities must be
carried out in an environmentally aware
manner.

2.5 PARTS

All DAF parts and components have been
carefully attuned to each other, a decisive factor
in ensuring the original DAF quality.
It is only logical, therefore, that the original DAF
quality can be maintained best if original DAF
parts and components are used when replacing
parts or components.
As far as maintenance activities are concerned,
this includes components such as windscreen-
wiper blades, air-dryer elements, gaskets, V-belts
and filters.
For example, if "non-original DAF filters" are
used, the engine will be insufficiently protected
against fine microscopic airborne dust particles,
almost imperceptible metal swarf in the oil and
dirt in the fuel, resulting in:

-

premature replacing of cylinders, pistons,
bearings, valves, injector pump and other
moving parts

-

reduced engine performance

-

increased fuel consumption

Therefore, always use original DAF parts and
components.

G000183

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

2-4

©

 200423

General

5

ΧΦ85 series

2.6 MAINTENANCE GUIDELINES

-

When carrying out maintenance activities on
the vehicle, it is important that the work is
performed under the cleanest possible
conditions.
Filler caps, lubricating points, filler and drain
plugs should be cleaned before and after
maintenance activities.

-

When excessive leakage has been detected
at oil seals and/or components, or in case of
excessive drops in the oil level, a report
should be made and the cause should be
remedied.

-

It is important to check the gearbox
breathers, transfer box, rear axle and driven
front axle regularly for fouling and blockages.
If the breathers are blocked by dirt,
overpressure may cause leaks.

-

Depending on the circumstances in which
the vehicle is used, e.g. on very bad roads or
construction sites, important bolt
connections such as the fifth wheel, spring
suspension, U-bolts, trailer coupling,
steering box attachment, superstructure
attachments etc. should be inspected more
often and, if necessary, be retightened.

-

It is important that a visual inspection and
test run are carried out following the
maintenance activities.
Particular attention should be paid to
components directly related to driving safety.

-

Once a service has been completed new
information on the next service (mileage/
date) can be entered on the instrument panel
display using DAVIE XD via the VIC.

©

 200423

3-1

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ85 series

5

3. INSPECTION AND ADJUSTMENT

3.1 CHECKING PEDAL RUBBERS

1.

Check that the pedal rubbers are still
securely mounted on the pedal.

2.

Check that the pedal rubbers are not worn
out and there is still sufficient tread.

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-2

©

 200423

Inspection and adjustment

5

ΧΦ85 series

3.2 CHECKING THE BATTERY FLUID LEVEL

Avoid sparks and open flames in the
vicinity of batteries.
Battery acid is an aggressive fluid.
In the event of contact with the skin:
rinse the skin with plenty of water for
a sustained period. If redness or
pain persists, consult a doctor.
Remove any clothing affected and
rinse with water.
In the event of contact with the eyes:
rinse with plenty of water for at least
15 minutes and consult a doctor.
If swallowed: do NOT induce
vomiting. Rinse the mouth, drink two
glasses of water and consult a
doctor.
In the event of inhalation: get fresh
air, rest and consult a doctor.

1.

Check the electrolyte level. The electrolyte
level must be approx. 10 mm above the
plates or up to the level indicator if available.

2.

If necessary, top up the batteries, see
chapter "Draining and filling".

3.3 CHECKING THE BATTERY TERMINALS

1.

Visually check the battery terminals for
corrosion. Clean the battery terminals if
necessary, see chapter on "Cleaning".

2.

Check the attachment of the battery
terminals.

}

M5011
