7-1

Lubrication

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ75 series

5

7. LUBRICATION

7.1 LUBRICATE ACCORDING TO X-SERVICE LUBRICATION SCHEDULE

Lubrication
Check whether the lubricating points stated

below are applicable.

Note:

The lubricating points marked below with an (S)

indicate that the lubricating point is positioned on

both the left-hand and right-hand side of the

vehicle.

Lubricating stub axles (S)
1.

To make sure that the grease can penetrate

adequately, the stub axles should be

lubricated in unloaded condition. The front

axle should therefore be completely jacked

up.

2.

Lubricate the stub axles until grease comes

out.

G000189

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

7-2

©

 200423

Lubrication

5

ΧΦ75 series

Lubricating the fifth wheel

Lubricating the air-sprung front axle (S)

Lubricating the leaf-sprung trailing axle (S)

G000192

G0 00 193

G000191

©

 200423

7-3

Lubrication

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ75 series

5

Lubricating the leaf-sprung tandem axle (S)

Lubricating the trailer coupling

G000187

G000188

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

7-4

©

 200423

Lubrication

5

ΧΦ75 series

Lubricating the rear axle brake camshaft (S)
(drum brake version)

Lubricating the drive shaft universal joint
1.

Grease the universal joints of the drive shaft

until the grease comes out of all 4 needle

bushes.

Note:

If the grease does not come out of all 4

needle bushes, the joint may be turned to

soften hardened grease.

If the grease does not come out of all 4

needle bushes after the drive shaft has been

repeatedly turned, the joint needs to be

replaced.

The maximum lubricating pressure should

not exceed 15 bar.

G000194

G0 00 267

V300899
