 200423

2-3

General

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ75 series

5

2.4 ENVIRONMENT

By carrying out the maintenance activities in a

professional manner, on time and at regular

intervals, you will help to reduce the impact on the

environment.

This means, for example, noticing and remedying

possible leakages in time and keeping the engine

in an optimum condition (adjusting valves,

replacing air filter element etc.), thus reducing the

emission of harmful exhaust gasses.

It should be noted that oils and fluids contain

harmful substances that have a negative impact

on the environment.

That is why you should take care that drained oils

and fluids and also discarded oil and fuel filters,

are collected in separate receptacles or

containers.

In short: maintenance activities must be

carried out in an environmentally aware

manner.

2.5 PARTS

All DAF parts and components have been

carefully attuned to each other, a decisive factor

in ensuring the original DAF quality.

It is only logical, therefore, that the original DAF

quality can be maintained best if original DAF

parts and components are used when replacing

parts or components.

As far as maintenance activities are concerned,

this includes components such as windscreen-

wiper blades, air-dryer elements, gaskets, V-belts

and filters.

For example, if "non-original DAF filters" are

used, the engine will be insufficiently protected

against fine microscopic airborne dust particles,

almost imperceptible metal swarf in the oil and

dirt in the fuel, resulting in:

-

premature replacing of cylinders, pistons,

bearings, valves, injector pump and other

moving parts

-

reduced engine performance

-

increased fuel consumption

Therefore, always use original DAF parts and

components.

G000183

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

2-4

©

 200423

General

5

ΧΦ75 series

2.6 MAINTENANCE GUIDELINES

-

When carrying out maintenance activities on

the vehicle, it is important that the work is

performed under the cleanest possible

conditions.

Filler caps, lubricating points, filler and drain

plugs should be cleaned before and after

maintenance activities.

-

When excessive leakage has been detected

at oil seals and/or components, or in case of

excessive drops in the oil level, a report

should be made and the cause should be

remedied.

-

It is important to check the gearbox

breathers, transfer box, rear axle and driven

front axle regularly for fouling and blockages.

If the breathers are blocked by dirt,

overpressure may cause leaks.

-

Depending on the circumstances in which

the vehicle is used, e.g. on very bad roads or

construction sites, important bolt

connections such as the fifth wheel, spring

suspension, U-bolts, trailer coupling,

steering box attachment, superstructure

attachments etc. should be inspected more

often and, if necessary, be retightened.

-

It is important that a visual inspection and

test run are carried out following the

maintenance activities.

Particular attention should be paid to

components directly related to driving safety.

-

Once a service has been completed new

information on the next service (mileage/

date) can be entered on the instrument panel

display using DAVIE XD via the VIC.

©

 200423

3-1

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ75 series

5

3. INSPECTION AND ADJUSTMENT

3.1 CHECKING PEDAL RUBBERS

1.

Check that the pedal rubbers are still

securely mounted on the pedal.

2.

Check that the pedal rubbers are not worn

out and there is still sufficient tread.

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-2

©

 200423

Inspection and adjustment

5

ΧΦ75 series

3.2 CHECKING THE BATTERY FLUID LEVEL

Avoid sparks and open flames in the

vicinity of batteries.

Battery acid is an aggressive fluid.

In the event of contact with the skin:

rinse the skin with plenty of water for

a sustained period. If redness or

pain persists, consult a doctor.

Remove any clothing affected and

rinse with water.

In the event of contact with the eyes:

rinse with plenty of water for at least

15 minutes and consult a doctor.

If swallowed: do NOT induce

vomiting. Rinse the mouth, drink two

glasses of water and consult a

doctor.

In the event of inhalation: get fresh

air, rest and consult a doctor.

1.

Check the electrolyte level. The electrolyte

level must be approx. 10 mm above the

plates or up to the level indicator if available.

2.

If necessary, top up the batteries, see

chapter "Draining and filling".

3.3 CHECKING THE BATTERY TERMINALS

1.

Visually check the battery terminals for

corrosion. Clean the battery terminals if

necessary, see chapter on "Cleaning".

2.

Check the attachment of the battery

terminals.

}

M5011
