1-1

Maintenance intervals

MAINTENANCE SCHEDULE

ΧΦ75 series

4

1. MAINTENANCE INTERVALS

1.1 MAINTENANCE SCHEDULE

The service intervals stated in the

maintenance schedule are based on use of

the oils and fuels specified by DAF.

+

+

Maintenance

schedule

CF75

1x per YEAR

G000233

Intermediate  X service

 Y service

30.000 km

50.000 km

75.000 km

30.000 km

37.500 km

50.000 km

60.000 km

75.000 km

1 year

max. 100.000 km

1 year

max. 100.000 km

1 year

max. 150.000 km

3 year

max. 180.000 km

3 year

max. 300.000 km

3 year

max. 450.000 km

1 year

max. 100.000 km

1 year

max. 100.000 km

1 year

max. 200.000 km

2 year

max. 120.000 km

3 year

max. 300.000 km

3 year

max. 450.000 km

100.000 km

inspection

Ext.

Ext.

Ext.

(1)

(4)

(3)

(2)

(2)

(1)

Automatic gearboxes are subject to different

changing intervals; see maintenance schedule

notes.

(2)

Extended changing intervals not permitted on 1354

and 1355(T) rear axles.

(3)

1 year/maximum 150,000 km for:

- 1132 and 1339 rear axles

1 year/maximum 100,000 km for:

- 1132(T), 1354 and 1355(T) rear axles

(4)

3 years/maximum 300,000 km for:

- 1132(T) rear axle

Extended changing intervals not permitted on 1354

and 1355(T) rear axles.

MAINTENANCE SCHEDULE

1-2

©

 200423

Maintenance intervals

4

ΧΦ75 series

1.2 EXPLANATORY NOTES ON THE MAINTENANCE SCHEDULE

Maintenance group classification
Depending on the use to which the vehicle is

put, the vehicle is placed in maintenance group I,

II or III.

Maintenance group I
Operation on building sites, in quarries, etc.

-

Operation on unmetalled roads

-

Traffic in dusty conditions

-

Sanitation department vehicles

-

Distribution transport with an annual mileage

of up to 30,000 km.

Maintenance group II
Urban and regional transport

-

Distribution traffic in urban areas

-

Traffic between adjacent villages/cities

Maintenance group III
(Inter)national traffic

-

Long-distance/very long-distance traffic

Standard changing interval
This is the standard changing interval symbol.

See the "Fluids and lubricants" specifications

manual for the prescribed oil specification.

Extended changing interval
This is the extended changing interval symbol.

If the prescribed oil specification and any

additional conditions (see specification manual

"Fluids and lubricants") are complied with, an

extended changing interval may be applied.

Note:

An extended changing interval for engine oil may

be subject to additional conditions. These

additional conditions are included in the "Fluids

and lubricants" specification manual.

G0  00 230

Ext.

G0  00 229

©

 200423

1-3

Maintenance intervals

MAINTENANCE SCHEDULE

ΧΦ75 series

4

Intermediate inspection
This is the intermediate inspection symbol.

Intermediate inspections are based on several

visual inspections.

When an extended changing interval is

applicable to the engine oil (X-service), an

intermediate inspection should be carried out.

X-service
This is the symbol for an X-service.

An X-service is a mileage-dependent

maintenance check which consists of changing

the engine oil plus a number of visual inspections.

Note:

If the prescribed oil specification and additional

conditions (see specification manual "Fluids and

lubricants") are met, an extended changing

interval (X-service) may be applied.

-

An X-service must be carried out at least

once a year.

Y-service
This is the symbol for a Y-service.

A Y-service is an annual maintenance check

consisting of several maintenance activities plus

changing of the gearbox and rear axle oil.

Note:

-

If the prescribed oil specification (see

specification manual "Fluids and lubricants")

has been met, an extended changing interval

may be applied.

-

Automatic gearboxes are subject to different

changing intervals.

G000088

Intermediate

inspection

G000086

+

 X service

G000087

+

1x per YEAR

 Y service

(1)

Automatic Allison gearbox

Maintenance group I

Standard changing interval 1 year/maximum 40,000 km

Extended changing interval 3 years/maximum 80,000 km

Maintenance group II

Standard changing interval 1 year/maximum 40,000 km

Extended changing interval 3 years/maximum 160,000 km

Maintenance group III

Standard changing interval 1 year/maximum 40,000 km

Extended changing interval 3 years/maximum 160,000 km

MAINTENANCE SCHEDULE

1-4

©

 200423

Maintenance intervals

4

ΧΦ75 series

1.3 EFFECT OF DIESEL FUEL AND PTO HOURS ON MAINTENANCE INTERVALS

Diesel fuels

PTO hours
PTO hours should be converted into mileage

according to the following formula:

1 PTO hour = 40 km

1.4 MAINTENANCE IN SPECIAL OPERATING CONDITIONS

Contact a DAF dealer/main branch or importer for

vehicles used in very specific or heavy

conditions.

The service intervals can be modified, if

necessary, in consultation with the dealer/main

branch or importer to fit the appropriate operating

conditions.

1.5 FIRST SERVICE INSPECTION

The first service inspection should be carried out

between the first 7,500 and 10,000 km or at most

8 weeks after delivery of the vehicle, whichever

comes first.

Note:

If the vehicle is equipped with a clutch wear

indicator, ensure that the lock nut makes contact

with the servo housing.

If necessary, make sure that the lock nut makes

contact with the housing.

The oil for the 1355 (T) axle must be renewed

between the 2,000 and 3,000 km.

Sulphur content

Engine oil change interval

> 0,2%

Halve interval to max. of 25,000 km
