 200518

7-1

Lubrication

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

7. LUBRICATION

7.1 LUBRICATE ACCORDING TO X SERVICE LUBRICATION SCHEDULE

Lubrication
Check whether the lubricating points stated

below are applicable.

Note:

The lubricating points marked below with an (S)

indicate that the lubricating point is positioned on

both the left and right hand side of the vehicle.

Lubricating stub axles (S)
1.

To ensure that the grease can penetrate

adequately, the stub axles should be

lubricated in unloaded condition. The front

axle should therefore be completely jacked

up.

2.

Lubricate the stub axles until grease comes

out.

Lubricating the trailer coupling

G000189

G000188

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

7-2

©

 200518

Lubrication

5

ΧΦ65/65 (II) series

Printed in the Netherlands

DW13280404

English
