DAF CF65, CF75, CF85 Series . Manual - part 1132

©

 200518

3-37

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

3.36 CHECKING THE GREASED WHEEL HUBS FOR LEAKS

1.

Check the wheel hubs for leaks.

Note:

If there are serious grease marks on the brake

disc side of the wheel hub, this could indicate

excessive use of assembly grease on new or

recently assembled wheel hubs.

On wheel hubs that have not been assembled

recently, serious grease marks could indicate a

leak in the seal (1). This means that the entire hub

unit must be replaced.

Serious oil leakage on the driven rear axle hubs

could indicate that the O-ring (2) is not sealing

correctly.

If there is an oil leak the hub unit should be

dismantled to remedy the problem.

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-38

©

 200518

Inspection and adjustment

5

ΧΦ65/65 (II) series

3.37 CHECKING THE SHOCK ABSORBERS FOR ATTACHMENT AND LEAKS

1.

Visually inspect the attachment of the shock

absorbers and for any leaks.

3.38 CHECKING THE CONDITION AND ATTACHMENTS OF SPRING LEAVES,

SPRING CLAMPS AND U-BOLTS

Checking U-bolts
1.

Visually inspect the condition and

attachment of the U-bolts.

2.

When retightening the U-bolt nuts, the

attachment nut must not be slackened first

and then tightened to the specified torque;

see "Technical data".

3.39 CHECKING THE HINGE POINTS AND AXLE SUSPENSION FASTENING

(AIR SUSPENSION)

Torque rod
1.

Check the attachment of the torque rod and

torque rod supports.

2.

Check the pivots of the torque rod for wear

and play.

Stabiliser bar
1.

Check the attachment of the stabiliser bar

and stabiliser bar support.

2.

Check the pivots of the stabiliser bar for wear

and play.

Ball joints three-point fixation
1.

Check the attachment of the ball joints and

three-point fixation support.

2.

Check the ball joint housing for surface

cracks.

3.

Check the dust cover for damage.

©

 200518

3-39

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ65/65 (II) series

5

3.40 CHECKING THE AIR SUSPENSION BELLOWS

1.

Raise the chassis to driving height using the

remote control.

2.

Clean the air bellows using a cleaning cloth

or a soap solution, if required.

3.

Check the air bellows for cracks and

damage. If there are any cracks or damage

through which the webbing is visible, the air

bellows should be replaced.

4.

Check the air bellows, bellows seating and

air line connections for leaks.

Check that the air bellows are not chafing

against air lines, etc. when in the driving

position.

M9040

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-40

©

 200518

Inspection and adjustment

5

ΧΦ65/65 (II) series

3.41 CHECKING THE OPERATION OF THE AUTOMATIC LUBRICATION SYSTEM

1.

Check the system for line fractures and

operation of the jets.

2.

Check whether all lubricating points are

lubricated.

3.

Check the lubricant level in the reservoir. If

necessary, top up the reservoir, see chapter

"Draining and filling".

C900331
