DAF CF65, CF75, CF85 Series . Manual - part 1089

©

 200448

1-1

General

STABILISERS AND TORQUE RODS

ΧΦ65/75/85 series

9

4

1. GENERAL

1.1 OVERVIEW DRAWING, FRONT AXLE STABILISER

C9 00 292

2

6

1

8

7

9

3

5

4

11

12

13

10

14

1.

Flange bolt

2.

Shackle

3.

Silentblock

4.

Bracket

5.

Flange nut

6.

Stabiliser bar

7.

Flange bolt

8.

Silentblock

9.

Flange nut

10.

Flange bolt

11.

Bracket

12.

Bearing bush

13.

Bearing bush cover

14.

Flange nut

STABILISERS AND TORQUE RODS

1-2

©

 200448

General

4

ΧΦ65/75/85 series

9

1.2 OVERVIEW DRAWING, LEAF-SPRUNG REAR AXLE STABILISER

C9 00 425

11

1

3

4

6

7

9

8

13

15

12

16

10

2

5

14

1.

Circlip

2.

Bracket

3.

Axle

4.

Bearing bush

5.

Bracket

6.

Ring

7.

Circlip

8.

Flange bolt

9.

Bearing bush

10.

Stabiliser bar

11.

Bracket

12.

Attachment bolt

13.

Attachment nut

14.

Silentblock

15.

Ring

16.

Attachment nut

©

 200448

1-3

General

STABILISERS AND TORQUE RODS

ΧΦ65/75/85 series

9

4

1.3 OVERVIEW DRAWING, STABILISER OF LEAF-SPRUNG TRAILING AXLE

AND PARABOLIC LEAF-SPRUNG TANDEM AXLE

C9 00 426

11

1

3

4

6

7

9

13

8

15

12

16

10

2

5

14

1.

Circlip

2.

Bracket

3.

Axle

4.

Bearing bush

5.

Bracket

6.

Washer

7.

Circlip

8.

Flange bolt

9.

Bearing bush

10.

Stabiliser bar

11.

Bracket

12.

Attachment bolt

13.

Attachment nut

14.

Silentblock

15.

Ring

16.

Attachment nut

STABILISERS AND TORQUE RODS

1-4

©

 200448

General

4

ΧΦ65/75/85 series

9

1.4 OVERVIEW DRAWING, AIR-SPRUNG REAR AXLE STABILISER

C9 00 309

13

2

3

1

4 5

6

7

8

9

10

11

16

14

15

17

12

1.

Bracket

2.

Attachment bolt

3.

Ring

4.

Ring

5.

Attachment nut

6.

Silentblock

7.

Shackle

8.

Attachment bolt

9.

Ring

10.

Ring

11.

Attachment nut

12.

Silentblock

13.

Stabiliser bar

14.

Bearing bush

15.

Bearing bush cover

16.

Ring

17.

Attachment bolt
