© 200424 4-1 Draining and filling SINGLE REAR AXLE 1339 ΧΦ65/75/85 series 8 3 4. DRAINING AND FILLING 4.1 DRAINING AND FILLING, DIFFERENTIAL To prevent skin injury, avoid unnecessary contact with the drained oil. Draining the differential Position the vehicle on a level surface. 2. Remove the level check/filler plug (A) and drain plug (B). Drain the oil. 3. Fit the drain plug (B) using the special Torx wrench (DAF no. 1329493) and tighten to the specified torque; see "Technical data". Filling the differential Fill the differential via the level check/filler plug (A) with the specified quantity of oil, see "Technical data". 2. Check the oil level after approx. 5 minutes. The oil level should now have reached the level check/filler opening. See 'Inspection and adjustment". 3. Fit the level check/filler plug (A) using the special Torx wrench (DAF no. 1329493) and tighten to the specified torque; see "Technical data". } M8013 A B |
