DAF CF65, CF75, CF85 Series . Manual - part 74
©
200338
3-3
Threaded connections
TECHNICAL DATA
ΧΦ65/75/85 series
0
0
Overview of standard tightening torques for
DAF clamping flange bolts and nuts, strength
class 12.9/12
Overview of tightening torques, banjo bolts
Torque wrench
-
Have torque wrenches regularly inspected
and calibrated.
Re-use of fasteners (bolt/nut/threaded end)
1.
Clean the thread (take particular care to
remove locking compound residues) and the
clamping faces
2.
Check the thread for damage.
To do so, manually screw a new nut/bolt onto
the thread to be checked.
If the new nut/bolt cannot be fully hand-
screwed onto the entire thread of the
fastener to be checked, the fastener is not
allowed to be re-used.
3.
Apply one drop of engine oil to the upper turn
of the bolt (threaded end)/lower turn of the
nut and one drop to the clamping faces
(other lubricants are not allowed).
4.
If a locking compound has been specified, oil
should not be applied to the thread.
Thread
Tightening torque in
Nm
M12
178
≥ 14
M14
274
≥ 22
M16
425
≥ 35
M18
550
≥ 45
Thread
Tightening torque in
Nm
M6
8
≥ 0.8
M8
15
≥ 1.5
M10
30
≥ 3
M12
40
≥ 4
M14
50
≥ 5
M16
60
≥ 6
M18
70
≥ 7
