Citroen C4 Aircross (2017 year). Instruction - part 21

319

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

RADIO

Selecting radio source

Press the RADIO button to switch on

the radio.

Press the RADIO

button repeatedly

to select the waveband; it changes in

the following order: FM1 / FM2 / FM3 /

MW / LW / FM1...

Automatic station search

Manual station search

Turn the SEL

knob to the left to search

the lower frequencies or to the right to

search the higher frequencies.

Press the "9" or ":" button to search

the lower frequencies or the higher

frequencies respectively.

The search begins automatically and

stops at the first station found.

Selecting the waveband

Selection / Presetting

320

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

Press one of the six buttons "1" to "6" until an

audible signal is heard.

The sound cuts out then becomes audible again

when the station has been preset.

The number of the button and the associated radio

frequency appear in the screen.

Manual station presetting

To recall the pre-set stored setting, press the button and release it

within two seconds.

RADIO

You can preset up to six stations on each waveband.

Presetting a new station replaces the previous station.

Automatic station presetting

Disconnecting the battery terminals clears the preset radio stations.

Stations can only be preset automatically on wavebands FM1, FM2

and FM3.

Presetting new stations replaces the previous stations.

This presetting can be activated automatically irrespective of the

waveband selected.

Press the RADIO

button for more

than two seconds.

The six stations offering the best

reception are preset and classified

from the weakest to the strongest on

the six corresponding buttons.

Recalling preset stations

Press one of the six buttons "1" to "6". The station

corresponding to the waveband selected appears on

the screen.

321

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

RADIO

The "Radio Data System

" (RDS) function on the FM waveband

permits:

- access to the display of information, such as the name of the

station, ...

- listening to the same station while travelling through different

regions,

- temporary tuning to traffic information announcements.

Most FM stations use RDS. These stations transmit non-audible

data in addition to their programmes.

The data transmitted in this way allows you access to various

functions, mainly displaying of the name of the station, automatic

retuning to alternative frequencies or temporary retuning to traffic

information announcements.

RDS allows you to continue listening to the same station by means

of alternative frequencies that carry the same station. However, in

certain conditions, RDS alternative frequencies may not be provided

throughout the country. Radio stations do not cover the whole

country, which explains the loss of reception of the station during a

journey.

"AF" alternative frequencies

Your radio automatically checks and selects the best frequency for

the radio station to which it is tuned (if the station broadcasts on

several transmitters or frequencies).

The frequency of a radio station covers approximately 30 miles

(50 km). The change from one frequency to another explains the

temporary loss of reception during a journey.

If the station to which you are listening does not have several

frequencies in the region in which you are currently located, you can

deactivate alternative frequencies.

Some stations are organised in a network.

In different regions, they broadcast different or shared programmes

depending on the time of day.

You can follow:

- a regional station only,

- the entire network, with the possibility that you will be listening

to a different programme.

REG regional mode

On long distance journeys, when the stored station becomes

weak, the radio searches first for another frequency for the

same station (AF). Then, if this fails, it searches for a frequency

broadcasting the regional programme (REG). If this also fails, the

radio returns to the stored station.

RDS

Press the MENU

button.

Press the SEL

knob repeatedly to

select the RDS

mode: "AF", "REG"

and "TP" then turn the knob to select

the desired value.

322

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

RADIO

"TP" traffic information

The "

Traffic Programme" (TP) function permits automatic

and temporary switching to an FM station broadcasting traffic

information.

The radio station or the source that you are listening to at this point

is put on hold.

Once the traffic information has ended, the system switches back to

the radio station or the source that you were listening to initially.

Press the TP

button.

"TP" appears in the screen. If the

station is compatible, "RDS" also

appears.

If the radio detects traffic information, "TRAF INF" appears on the

display, followed by the frequency of the broadcasting station, then

its name.

The volume is different from that of the previous source.

Following the broadcasting of the traffic information, the volume

returns to that of the source prior to the interruption.

When "TP" appears in the screen, the radio stops only at RDS

stations broadcasting traffic information.

"ALERT" emergency broadcasts

An emergency broadcast automatically and temporarily interrupts

the FM station or the source that you are listening to.

The message "ALERT" appears in the screen and the volume is

different from that of the previous source.

Following the emergency broadcast, the message disappears and

the volume returns to that of the source prior to the interruption.

"PTY" themed type of programme

Some stations offer the option of listening to a themed type of

programme as a priority, selected from the list available below:
NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA, CUlTURE,
SCIENCE, VARIED, POP M, ROCK M, EASY M, lIGHT M,
ClASSICS, OTHER M, WEATHER, FINANCE, CHIlDREN,

SOCIAL, RELIGION, PHONE IN, TRAVEL, LEISURE, JAZZ,

COUNTRY, NATION M, OLDIES, FOLK M, DOCUMENT.

323

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

RADIO

Search for a "PTY" broadcast

Press the PTY/SCAN

button.

Ten seconds after reception, the PTY mode is cancelled.

Press one of the six buttons "1" to "6" for more than

two seconds.

The sound cuts out then becomes audible again

when the programme has been stored.

The number of the button and the associated PTY

programme appear in the screen.

Presetting a "PTY" programme

You can preset up to six PTY programmes.

Each new programme stored replaces the previous one.

Turn the SEL

knob to select PTY

mode; the symbol flashes and an

automatic search is made.

Once the station has been found, its

name appears in the screen.

Press the "9" or ":

" buttons to find

another station.

Press the PTY/SCAN

button.

Turn the SEL

knob to select PTY

mode, then press one of the six

buttons "1" to "6" to define the preset

location.

324

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

RADIO

Changing the display language of the "PTY" programme

Functions setting mode

This permits activation or deactivation

of the functions below.
Press the SEL

knob repeatedly; the

setting mode for the functions changes

in the following order: GRACENOTE

DB / AF / REG / TP-S / PI-S / PTY

(languages) / PH setting / CT / OFF.

The functions setting mode is deactivated after approximately

10 seconds without any action.

Press the MENU

button.

Press the SEL

knob repeatedly to

select the PTY lang

mode.

Turn the SEL

knob to select the

language (ENGLISH, FRANCAIS,

DEUTSCH, SVENSK, ESPAGNOl,

ITALIANO).

Press then MENU

button.

Turn the SEL

knob to the left to

deactivate the function ("OFF") or to

the right to activate it ("ON").

325

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

RADIO

DAB (Digital Audio Broadcasting)
Digital radio

Press the RADIO

button repeatedly to

select the waveband; this changes in

the following order: FM1 / FM2 / FM3 /

DAB1 / DAB2 / DAB3 / MW / LW.

Selecting the waveband

Digital radio provides a superior audio quality and also additional

categories of traffic announcements.

The different channels offer a choice of radio stations in alphabetical order.

Automatic station search

Manual station search

Turn the SEL

thumbwheel respectively

to the left to search for lower

frequencies or to the right to search for

higher frequencies.

Press button "7" or "8" respectively

to search for lower or higher

frequencies.

The search begins automatically and

stops on the first station found.

Press one of the six buttons "1" to "6" until an

audible signal is heard.

The sound cuts out, then becomes audible again

after storing.

The number of the button and the frequency of the

associated radio station appear on the display.

Storing stations

To retrieve the pre-set memory setting, press the button and release

it within two seconds.

You can store up to six stations for each waveband.

Each new stored station replaces the previous station.

"DAB" does not have 100% coverage of the country.

When the digital signal is weak, "DAB" allows you to continue

listening to the same station, by automatically switching to the

corresponding analogue "FM" station (if it exists).

326

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

MUSIC MEDIA PLAYERS

This can play audio CDs (CD-DA, CD-Text, CD-R/RW) or

MP3 CDs.

Ejecting a disc

CD player

Selecting CD mode

If the player already contains a disc,

press the MEDIA

button.

"MEDIA", the track number and the

playing time appear in the screen.

Insert circular compact discs only.

8 cm compact discs must be inserted in the centre of the player slot.

After inserting a disc, printed face upwards, the player starts

automatically.

Press this button to remove the

disc from the player. The system

automatically switches to radio mode.

Once ejected, if the compact disc is not removed within

fifteen seconds, it is reloaded into the player.

327

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

MUSIC MEDIA PLAYERS

Random playing of a disc

Press the RDM

button to start random

play of the tracks on the disc. "RDM"

appears in the screen.

To exit this mode, press this button

again.

Audio CD

Press and hold the "7" or "8" button

to carry out a rewind or fast forward

search respectively.

Play begins when the button is

released.

Fast search

Press the "9" or ":" button to select

the previous or next track respectively.

Selecting a track

Press the RPT button to repeat

the play of the current track. "RPT"

appears in the screen.

To exit this mode, press this button

again.

Repeating a track

Playing the beginning of each track

Press the PTY/SCAN button to start

playback of the first ten seconds

of each track on the disc. "SCAN"

appears in the screen and the

corresponding track number flashes.

To exit this mode, press this button

again.

On CD-R/RWs, the quality of the playback sound depends on the

encoding software, the burning device and the burning speed used.

328

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

CD-TEXT display

Press the DISP

button repeatedly; the

CD-Text information appears in the

following order:

DISC NAME / TRACK NAME /

NORMAL DISPLAY MODE.

The CD player is compatible with the display of CD-Text

information.

In the case of compact discs containing both CD-DA and MP3 files,

play automatically begins with the CD-DA files.

To switch play between the two types of file, press the CD button for

more than two seconds until an audible signal is heard.

While using these compact discs, the "Repeat", "Random play" and

"Playing of the beginning of the tracks" functions are only applied to

files of the same format.

If the information exceeds

12 characters, press the PAGE button

to see the rest.

In the absence of CD-Text information

to be displayed, "NOTITLE" appears

on the screen.

MP3 / ID3 Tag CD

Selecting an MP3 folder

Turn the SEL

knob to the right to

select a folder in ascending order or to

the left to select a folder in descending

order.

The CD player and the CD changer are compatible with the playing

of MP3 files.

These must be recorded in ISO-8859 Level 1 / Level 2, Joliet or

Romeo format on CD ROMs, CD-Rs or CD-RWs. The CDs can

contain a maximum of 255 files and 100 folders on 16 levels.

The ID3 version 1.0, 1.1, 2.2, 2.3 and 2.4 Tag can be displayed

while playing MP3 files.

MUSIC MEDIA PLAYERS

329

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

MUSIC MEDIA PLAYERS

Repeating the tracks in a folder

Press the RPT

button for more than

two seconds to repeat the playing of

the tracks contained in the current

folder. "D-RPT" appears in the screen.

To exit this mode, press this button

again.

Press the RDM

button to start random

playing of the tracks in the current

folder. "RDM" appears in the screen.

To exit this mode, press this button

again.

Playing the beginning of each track

MP3 / ID3 Tag display

Press the DISP

button repeatedly;

the MP3 information appears in the

following order:

FOLDER NAME / TRACK NAME /

NORMAL DISPLAY MODE.

Press the PTY/SCAN button to start

playing the first ten seconds of each

track in all of the folders. "SCAN"

appears in the screen and the

corresponding track number flashes.

To exit this mode, press this button

again.

Random playing of a folder

Random playing of a disc

Press the RDM

button for more than

two seconds to start random playing of

the tracks in all of the folders. "D-RDM"

appears in the screen.

To exit this mode, press this button

again.

When play begins, "READING" appears in the screen then

disappears to make way for the folder number, the track number,

the playing time and "MP3".

330

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

Press the DISP

button for more than

two seconds to activate the ID3 Tag

information. "TAG" appears in the

screen.
Press the DISP

button repeatedly; the

Tag ID3 information appears in the

following order:

ALBUM NAME / TRACK NAME /

ARTIST NAME / NORMAL DISPLAY

MODE.

To deactivate this information, press

the DISP

button again for more than

two seconds.

If the information exceeds

12 characters, press the PAGE button

to see the rest.

In the absence of MP3 or ID3

Tag information to be displayed,

"NOTITLE" appears in the screen.

On CD-R/RWs, the quality of the playing sound depends on the

encoding software, the burning device and the burning speed used.

Depending on the flow chart of the MP3 folders and files on the

disc, play may not begin immediately.

MUSIC MEDIA PLAYERS

Using the auxiliary input (AUX)

The auxiliary socket allows the

connection of a portable device

(MP3 player...).

Connect the portable device (MP3 player…) to the RCA audio

sockets (red and white) using a suitable cable, not supplied.

First adjust the volume on your portable device (to a high level).

Then adjust the volume on the audio system.

Operation and play is done using the controls on your portable

device.

Press the MEDIA

button for more

than two seconds.

"AUX" appears in the screen and the

external mode is activated.
Press MEDIA

again to deactivate the

AUX

mode and change to another

mode.

331

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

USB PLAYER

Using the USB port

With the vehicle stationary, ignition

switch in the LOCK position, connect

a suitable cable to the portable player.

The USB port is used to connect a

portable device (MP3 player, Apple

player, etc.). The files are sent from the

player to your audio system and heard

through the vehicle's speakers.

Then connect the cable to the

vehicle's USB port.

Use only USB memory sticks in the format FAT32 (File Allocation

Table).

File formats: MP3, WMA, AAC, WAV.

- Maximum number of levels (including root): 8.

- Number of folders: 100.

- Number of files: 255.

To disconnect the cable, the ignition switch must be in

the LOCK

position.

Take care not to trap the cable when closing the armrest.

To protect the system, do not use a USB hub.

332

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

Once the portable player / iPod

connected, make several successive

presses on the MEDIA

button and

select USB, the source selected is

displayed.

Once the player is selected, play

starts.

Play

Managing a track (or folder)

Stop

Press MEDIA

to change mode or on

RADIO

Turn the knob to select a previous or

next track.

Select a folder (or track)

Select a track

Press the knob to select the folder

and go down or up one level.

The knob can also be used for tracks.

USB PLAYER

Press the "7" or "8" button to select

the previous or next track respectively.

Press and hold to go faster.

Playing the start of each track

Press the PTY/SCAN button to start

the play of the first ten seconds of each

track in all folders. "SCAN" appears in

the screen and the corresponding track

number flashes.

Press this button again to quit this

mode.

333

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

Play

Managing a track

Pause / Stop / Resume*

BLUETOOTH

STREAMING

Press and hold the ";" button to

pause the play.

Press the "Back" button to stop play.

Press this button to start play.

Select a track*

Repeat play*

Press this button during play.

Press again to exit this mode.

Press this button during play.

Press again to exit this mode.

* If the function is supported by the device.

Random play*

Streaming allows music files on a telephone to be heard via the vehicle's

speakers.

The telephone must support the appropriate Bluetooth

profiles

(profiles A2DP / AVRCP).

Connect the telephone: see the "BLUETOOTH

TElEPHONE WITH

VOICE RECOGNITION" section.

Press the MEDIA

button repeatedly

and select Bluetooth

(the source

selected is displayed).

Press the "7" or "8" button to select

the previous or next track respectively.

334

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

Press this button.

"PTY/SCAN" appears in the screen

and the start of each track on the

telephone connected via Bluetooth

played for around 10 seconds.

Press again to exit this mode.

Play the start of each track*

Changing the display*

Press and hold this button until an

audible signal is heard and "TAG" is

displayed.

Press this button to change the

display.

Make a new long press to exit this

mode.

The screen displays a maximum of 11 characters at a times. If

the end of the title is cut off, press the PAGE button. The next

characters are displayed each time the button is pressed.

If no title is stored: "NO TITLE" appears in the screen.

Characters that cannot be displayed are replaced by ".".

* If the function is supported by the device.

BLUETOOTH

STREAMING

Content .. 19 20 21 22 ..
