303

C4-Aircross_en_Chap10c_Mitsu5_ed01-2016

RADIO

Selecting a DAB (Digital Audio Broadcasting) station - digital radio

The exterior environment (hills, buildings, tunnels, car parks, being underground, etc.) may prevent reception, even in RDS station tracking mode.

This phenomenon is normal in the propagation of radio waves and is in no way indicative of a fault with the audio system.

Select "DAB

Press MENU

to display the source selection.

Select a station from the list (1 to 6) or use

"Tune

" to change the frequency.

Maintain the pressure on "Tune" until a

beep is heard to search for the next station

automatically.

Press the arrow

to adjust the DAB or the sound

quality (balance, equaliser, etc.).

Press "Station list

" to display the list of radio

stations received in your area.

Pressing and holding one of the numbers stores

the current station.

Digital radio provides a superior audio quality and also a display of graphic current information concerning the radio station selected.

The different channels offer a choice of radio stations in alphabetical order.

Store up to 18 stations between DAB1, DAB2

and DAB3.

304

RADIO

Setting the DAB

Select the arrow

Press the MENU button then select the
"DAB

" radio source.

Select "Setting" then "DAB Setting

Press the MENU button then "Next

then

Activate the settings as required.

305

C4-Aircross_en_Chap10c_Mitsu5_ed01-2016

Playing a CD (CD-DA/CD-TEXT or MP3/WMA/AAC)

Inset a CD then select "CD

Press the MENU

button to display the choice of

source.

Use the "Track

" button to select the previous /

next track.

MUSIC

Press and hold "Track" for rewind or fast

forward.

Press the arrow

to modify the track play mode:

"Repeat

": plays the current track repeatedly in

a loop.
"Scan

": plays the start of each track for around

10 seconds.
"

Random/Shuffle": plays all of the tracks in the

current folder in random order.
"Sound control

": settings for balance,

equaliser, etc.

Press "Track List

" to display the complete list

of tracks.

With an MP3/WMA/AAC CD, press "Folder" to

move up and down in the folders.

306

MUSIC

Using the USB port

With the vehicle stationary, ignition

switch in the LOCK position, connect

a suitable cable to the portable player.

The USB port is used to connect a

portable device (MP3 player, Apple

player, etc.). The files are sent from the

player to your audio system and heard

through the vehicle's speakers.

Then connect the cable to the

vehicle's USB port.

Use only USB memory sticks in the format FAT32 (File Allocation

Table).

File formats: MP3, WMA, AAC, WAV.

- Maximum number of levels (including root): 8.

- Number of folders: 100.

- Number of files: 255.

To protect the system, do not use a USB hub.

To disconnect the cable, the ignition switch must be in the LOCK

position.

Take care not to trap the cable when closing the armrest.

307

C4-Aircross_en_Chap10c_Mitsu5_ed01-2016

MUSIC

Using the auxiliary input (AUX)

The auxiliary input allows the

connection of a portable device

(MP3 player...).

Connect the portable device (MP3 player…) to the RCA sockets

(red and white) using a suitable cable, not supplied.

First adjust the volume of your portable device (to a high level).

Then adjust the volume of your audio system.

The operation and play is controlled on the portable device.

Press the MENU button, then the
"Next" button for access to the

secondary screen, then on "AUX".

308

Playing tracks on an iPod

Connect the iPod

then select "iPod

Press the MENU

button to display the choice of

source.

Use the "Track

" button to select the previous /

next track.

MUSIC

Press and hold "Track" for rewind or fast

forward.

Press the arrow

to modify the track play mode:

"Repeat

": plays the current track repeatedly in

a loop.
"

Random/Shuffle": plays all of the tracks in the

current folder in random order.
"Playback Speed

": adjustment of the play

speed (slow, normal, fast).
"Sound control

": settings for balance,

equaliser, etc.

Press "Chapter List

" to display the complete

list of audio book chapters.

Press "iPod Menu

" to display the list of

categories, then sort.

The choice of tracks will then be from the

category chosen.

309

C4-Aircross_en_Chap10c_Mitsu5_ed01-2016

Playing tracks on a portable player (USB)

Connect the portable player, then select "USB

Press the MENU

button to display the choice of

source.

Use the "Track

" button to select the previous /

next track.

MUSIC

Press and hold "Track" for rewind or fast

forward.

Press the arrow

to modify the track play mode:

"Repeat

": plays the current track repeatedly in

a loop.
"Scan

": plays the start of each track for around

10 seconds.
"

Random / Shuffle": plays all of the tracks in

the current folder in random order.
"Sound control

": settings for balance,

equaliser, etc.
"Database

": checks the version of

"Gracenote

*".

Press "Folder List

" to display the list of folders.

Press on a folder to run through the tracks.

Press "Folder

" to move up and down in the

folders.

Press "Playlist Mode", "Music Menu" is

displayed.

This allows tracks to be sorted by category.

* The Gracenote music database is a service that supplies the names of

albums, the track titles, etc.

310

BLUETOOTH

TELEPHONE

Press the MENU button, then "Next

" to display

the choice of source.

Activate the Bluetooth function on the telephone

and ensure that it is "visible to all" (refer to the

configuration instructions for your telephone).

Press "Phone

Press the arrow

Press "Bluetooth Setting

Press "Register Device

Pairing a Bluetooth

telephone from

the audio system

For reasons of safety and because the sustained attention of the

driver is needed, operations of matching a Bluetooth

mobile phone

with the audio system's hands-free function must be done with the

vehicle stationary

"Hands Free system

" should be displayed on

your telephone.

Select it and then enter the code displayed in

the audio system.

Your telephone is added to the list in the audio

system.
If necessary, refer to the instructions for your

mobile telephone.

The services available depend on the network, the SIM card and

the compatibility of the Bluetooth

telephone used.

Refer to the instructions for your telephone and to your service

provider for the services you have access to.

311

C4-Aircross_en_Chap10c_Mitsu5_ed01-2016

Making a call

BLUETOOTH

TELEPHONE

Press the "MENU" button, then "Next" to

display the choice of source

Press "Phone

Enter the number then press the telephone.

Managing paired telephones

Press the MENU button, then "Next

" to display

the choice of source.

Press "Phone

Press the arrow then press "Bluetooth
Setting

Use of the telephone is not recommended while driving. We

recommended that you park safely or make use of the steering

mounted controls.

Select or change a telephone already paired.

Pair/register a new telephone

Delete a paired telephone

312

313

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

AUDIO-CD system

The system is protected in such a way that it will only

operate in your vehicle.

01 First steps - Control panel

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is

stationary.

When the engine is switched off and to prevent

discharging of the battery, the system switches off

following the activation of the energy economy mode.

CONTENTS

02 Steering mounted controls

03 General operation

04 Radio

05 Music media players

06 USB player

07 BLUETOOTH

streaming

Error messages

314

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

Display the track.

Scroll through tracks.

Symbols:

i: iPod

U: USB.

B: Bluetooth

Random play in the current

folder.

Switch from audio CD

mode to USB / iPod

and

Bluetooth modes*.

Press and hold to change to

AUX mode.

Repeat the current track.

FIRST STEPS

Audio system on / off.

Volume adjustment.

Select radio source.

Select waveband (FW,

MW, LW).

Available according to version.

Eject CD.

Preset stations, buttons 1 to 6.

Short press: select preset radio

station.

Long press: preset a radio station.

315

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

FIRST STEPS

Fast back / forwards.

PTY On / Off.

Play the first 10 seconds

of each track in the current

folder.

Selection:

- automatically of the next

radio frequency down / up.

- of the previous / next track.

Select previous / next folder (or track).

Adjust audio settings.

Manual search up and down for a radio station / PTY.

Function setting mode (AF, REG, TP, SCV, ...).

Press: select folder (or track).

Search for TP traffic

information.

Play / pause the current track.

Abandon the current

operation, up one level.

Change to MENU mode.

316

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

STEERING MOUNTED CONTROLS

Increase / reduce audio volume.

Search for a higher / lower radio frequency.

Next / previous CD track.

CD fast forwards / backwards.

Long press: audio system on / off.

Short press: selection of the source in the

following order: FM1 / FM2 / FM3 / MW /

LW / CD.

317

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

GENERAL OPERATION

Press the PWR/VOL

button.

The last source selected before

switching off resumes operation.

The audio system functions can be

used when the ignition switch is in the

"ON" or "ACC" position.
To switch off, press the PWR/VOL

button again.

Adjusting the volume

Turn the PWR/VOL

knob to the left to

decrease the volume or to the right to

increase it.

Press the SEL

knob repeatedly; the

audio mode changes in the following

order: BASS / TREBLE / FADER /

BALANCE / SCV and cancel.

Setting the audio modes

Switching on / off

The audio adjustment mode is deactivated, during operation of the

radio or a CD or after around 10 seconds with no action.

Adjusting the audio modes

Turn the SEL

knob to the left or right

to adjust the audio setting.

318

C4-Aircross_en_Chap10d_Mitsu4_ed01-2016

"BASS" setting

Turn the SEL

knob to set the required

bass value.

GENERAL OPERATION

Turn the SEL

knob to set the required

treble value.

"FADER" front/rear sound distribution setting

"BALANCE" left/right sound distribution setting

Turn the SEL

knob to set the balance

of the volume of the right and left

speakers.

Turn the SEL

knob to set the balance

of the volume of the front and rear

speakers.

"SCV" automatic volume adjustment

"TREBLE" setting

This allows automatic adjustment of the settings in relation to the

vehicle speed.

Turn the SEL

knob for access to the

settings (OFF, LOW, MID, HIGH).

Press the SEL

knob repeatedly to

select "SCV" mode.
