Citroen DS5 (2016 year). Instruction

29
30

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Navigation

Select the orientation of the map; north up,
vehicle direction up or perspective.

Navigation

TOMTOM TRAFFIC

On connection of the system to a network,
"TOMTOM TRAFFIC" is displayed instead of
"TMC", for use of all of the options available, in
real time.

Navigation

Weather

Select the options.
The map display the route chosen, depending on
options.

Stations

Car park

Traffic

Danger area

Map color

Select the display mode for the map.

POI on map

Commercial

Select the POIs available.

Geographic

Leisure

Public

Travel

Confirm

Save the options.

View map

Modify city

Select or change a city.

Zoom out.

Zoom in.

31
32

Audio and Telematics

Level 3

Level 4

Level 5

Comments

Select city

Confirm

Select or change a city.

Around the vehicle

Select or change a city.

On the route

At the destination

Weather

Weather information

Display the weather forcast for the day or the
following days.

Filling stations

Filling stations around the vehicle

Display the list of filling stations and the
associated information (address, prices,
fuels, ...).

Filling stations on the route

Filling stations at the destination

By distance

By price

Car park

Car parks around the vehicle

Dsplay the list of car parks and the associated
information (address, distance, spaces available,
price, ...).

Car parks on the route

Car parks at the destination

Sort by distance

Sort by spaces

Sort by price

Zoom out.

Zoom in.

Audio and Telematics

Level 3

Level 4

Level 5

Comments

Traffic

Traffic observed

Display traffic information in real time: type,
description and duration (in minutes).

Danger areas

List of danger areas

Display danger areas (roadworks, breakdowns,
accidents, ...) in real time.

Points of interest

Points of
interest

Select POI

Display the list of POIs for the location selected.

Settings specific to

connected navigation

For access to connected navigation,
you have to select the option:
" Authorize sending information ".

Select " Options ".

Select " Alerts ".

- "

Allow declaration of danger

areas "

- "

Guidance to final destination

on foot "

- "

Authorise sending

information "

Activate or deactivate:

Activate or deactivate " Warn of
danger zones ".

The display of danger zones is
conditioned by the legislation in force
and subscription to the service.

The temperature displayed at 6 o'clock in the morning
will be the maximum temperature for the day.
The temperature displayed at 6 o'clock in the evening
will be the minimum temperature for the night.

Select " Settings ".

Press on Navigation to display the
primary page.

Press the " MENU " button to go to the
secondary page.

Display the weather

Select " Weather ".

Press on this button to display the
first level of information.

Press on this button to display the
detailled weather information.

Select " View map ".

Press on Navigation to display the
primary page.

Press on this button to display the list
of services.

Audio and Telematics

To distribute information on the
declaration of danger zones, you
should check the option: " Allow
declaration of danger areas ".

You can download updates to the
system, danger zones and mapping,
from the brand's website.
The download procedure can be found
in the same place.

Declaration of "Danger

areas"

Press on Navigation to display the
primary page.

Press on the "Declare a new danger
area" button located in the upper bar
of the touch screen.

Select the option " Type " to choose
the type de "Danger area".

Select the " Speed " option and enter
it using the virtual keypad.

Press on " Confirm " to save and
distribute the information.

Level 1

Level 2

Bluetooth connection

Wi-Fi network connection

Networks

Share Wi-Fi connection

Connections and subscriptions to services

Functionalities available according to equipment.

Audio and Telematics

Level 1

Level 2

Comments

Connectivity

Secondary page

Bluetooth

connection

All

Display all telephones, connected or
disconnected.

Connected

Display all connected telephones.

Search

Start a search for a device to connect.

Connectivity

Secondary page

Wi-Fi network

connection

Secured

Display secured Wi-Fi networks.

Not secured

Display non-secured Wi-Fi networks.

Stored

Display remembered Wi-Fi networks.

Connectivity

Secondary page

Manage connection

Display the state of the subscription to connected
services, the state of the network connection and
the connection mode.

Connectivity

Secondary page

Share Wi-Fi

connection

Activation

Activate or deactivating the sharing of the Wi-Fi
connection.

Settings

Select a Wi-Fi network found by the system and
connect to it.

Save settings.

Functionalities available according to equipment.

Bluetooth connection

Procedure from the system

Connection sharing

Press on " Telephone " to display the
secondary page.

Press on " Bluetooth connection ".

Select " Search ".
The list of deteted telephones is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The " Mobile internet data " profile
must be activated for connected
navigation (where the vehicle does not
have "Emergency and assistance call"
services), having first activated sharing
of this connection on your smartphone.

The system offers to connect the
telephone with 3 profiles:
- "

Telephone " (hands-free kit, telephone

only),

- "

Streaming " (wireless play of audio files

on the telephone),

- "

Mobile internet data ".

Select the name of the chosen
telephone in the list.

Press on " Confirm ".

Select one or more profiles.

Press on the " OPTIONS " button to
go to the secondary page.

  As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the vehicle stationary
and the ignition on.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

Audio and Telematics

Wi-Fi connection

Sharing the Wi-Fi connection

Managing connections

To protect from any piracy and provide
maximum security for your systems,
it is recommended that you use a
security code or complex password.

The Wi-Fi connection and the sharing
of the Wi-Fi connection are exclusive.

Press on " Confirm " to start the
connection.

Press on " Confirm ".

Press on " Connectivity " to display
the primary page.

Network connection by the smartphone Wi-Fi.

Creation of a local Wi-Fi network by the
system.

Press on Connectivity to display the
primary page.

Press on " OPTIONS " to go to the
secondary page.

Press on the " OPTIONS " button to
go to the secondary page.

Select " Wi-Fi network connection ".

Select " Share Wi-Fi connection ".

Select " Manage connection ".

And / Or

Select the " Secured ", " Not secured "
or " Stored " tab.

Select the " Activation " tab to
activate or deactivate sharing of the
Wi-Fi connection.

Select the " Settings " to change the
name of the system network and the
password.

With this function you can view the access
to connected services, the availability of
connected services and modify the connection
mode.

Using the virtual keypad, enter the
" Key " for the Wi-Fi network and the
" Password ".

Select a network.

Audio and Telematics

As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary .

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink

technology to be displayed

in the vehicle's screen.
The principles and standards
are constantly evolving. For the
communication process between
the smartphone and the system to
work correctly, the smartphone must
be unlocked; update the operating
system of your smartphone as
well as the date and time in the
smartphone and the system.
For the list of eligible smartphones,
connect to the brand's internet website
in your country.

The " MirrorLink

" function requires

the use of a compatible smartphone
and applications.

There may be a wait for the availability
of applications, depending on the
quality of your network.

When connecting a smartphone to
the system, it is recommended that
Bluetooth

be started on the smartphone

Depending on the smartphone, it may be
necessary to activate the " MirrorLink

" function.

During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and end the
connection.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press on " MirrorLink

" to start the

application in the system.

Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

From the system, press on
" Connectivity " to display the primary
page.

As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.
