Citroen C-Crosser (2012 year). Instruction - part 14

207

A U D I O a n d T E L E M A T I C S

Changing the playing mode

Press [ Track] to select the previous track or return to the beginning of

the track currently being played.
Press and hold for fast backwards play.

Selecting a track

Press [Track

] to select the next track.

Press and hold for fast forwards play.

Press [Repeat] to play the track selected in a loop (repetition).
Press [Repeat] again to play all of the tracks in the selected folder in a loop.
Press again to stop.

Press [Scan] to play the beginning of each track in each folder for

approximately 10 seconds (scanning).
Press [Scan] again the play the beginning of each track in the selected

folder in a loop.
Press again to stop or press on the current track (during the 10 seconds)

and play begins.

Press [Random] to play all of the tracks in the selected folder in random

order.
Press [Random] again to play all of the tracks on the CD in random order.
Press again to stop.

Press [^] to access the secondary menu.

Press

Explanations

Result

Playing an MP3/WMA CD (2/2)

208

A U D I O a n d T E L E M A T I C S

DVD MODE

The DVD button is only active if the

player contains a DVD.

Press Open to return the screen to the

vertical position.

For safety reasons, the video

is not displayed while driving,

however the audio can be

played.

To display the picture and watch a

DVD, park the vehicle in a safe place.

K. To display the DVD title menu.
L. To scroll up or down through the

chapters.

Press and hold for fast backwards

or forwards play.

  M.   To scroll up or down through the titles.
  N.   To enter a title or chapter number.
  O.   To change the angle.
  P.   To change the language of the sub-

titles.

Q. To change the language.
R. To select a chapter or title or specify

a number.

A. This icon is displayed when the opera-

tion requested cannot be carried out.

B. The number of the chapter currently

being played is displayed.

C. The number of the title currently

being played is displayed.

D. Symbols display the current status

of the player.

E. The playing time is displayed.
F. To resume normal play when play is

paused or during slow-motion play.

G. To stop play temporarily.
H. To stop play. Press the screen to

access the menu.

I. For slow-motion play.
J. To play the previously selected zone

on the disc.

Information displayed in DVD

mode

209

A U D I O a n d T E L E M A T I C S

Playing a DVD

Result

Explanations

Selecting a chapter

Press the MODE button then DVD, if the player already contains a DVD.

Otherwise, insert a DVD in the player, the picture is displayed

automatically. Press the screen to access the menus.

While driving, only the soundtrack is played and no picture is displayed.

Press [ Chapter] to select the previous chapter or return to the beginning

of the chapter currently being played.
Press and hold for fast backwards play.

Press [Chapter

] to select the next chapter.

Press and hold for fast forwards play.

Selecting a title

Press [ Title] to select the previous title.

Press [Title ] to select the next title.

Press

210

A U D I O a n d T E L E M A T I C S

A - Choose to switch off the display.

To switch it back on, touch the

screen or press any button.

B -

Choose the settings of the sound

in the vehicle, if an audio source

is selected (FM, CD, ...), for:

B1 -

the sound distribution or the volume

such as the front-rear balance, the

bass, the medium, the treble, the

volume adjustment in relation to the

vehicle speed,

B2 -

the type of music (with surround

option) such as classic, jazz, pop,

rock, hip hop, country, normal, ...

B3 -

the sound fi eld (with surround op-

tion) such as stage, live, hall, nor-

mal, ...

C  -  Choose the quality of the picture for:
C1  -  the colour (when playing DVDs),
C2 -

the intensity of the colours (when

playing DVDs),

C3 -  the brightness,
C4 -  the contrast,
C5  -  the level of black.

SETTINGS
Display, sound, picture

211

A U D I O a n d T E L E M A T I C S

Time and date, language, unit,

picture size

E - Choose the size of the DVD picture for:

E1 - normal 4/3,

E2 -

extends the picture evenly to the right

and to the left in wide screen mode,

E3 -

extends the right and left parts only

leaving the centre as it stands in

wide screen mode,

E4 - enlarges the picture in 4/3 format.

The top and the bottom are outside

the frame.

D -

Choose the base settings of the sys-

tem for:

D1 -

setting of the time by the RDS signal,

time zone, summer time,

D2 -

the language (English, Français,

Deutsch, Nederlands, Portuguese,

Español, Svenska, Italiano, Dansk),

D3 -

the units for calculation of the dis-

tances (km or miles and °C or °F),

D4 - other settings such as:

- the voice guidance volume,

- the type of voice guidance voice

(female or male),

- the volume of the operation bleeps

(1 to 3 and 0=no bleep),

- the type of inputting keypad (alpha-

bet or PC),

- the range of menu colours (red or

blue),

- the displaying or not of the audio

playing icons on the map screen,

- the reinitialisation of the vehicle sensor,

- the interruption or not of the display

when the air conditioning is used.

212

A U D I O a n d T E L E M A T I C S

Equipment, contrast, traffic information (TP)

- Choose to adjust or set the param-

eters of certain equipment offered

in your vehicle (e.g.: unfolding/

folding of the mirrors, closing the

windows on locking, timing and

sensitivity of the automatic light-

ing, direction indicators motorway

function, ...):

F1  -  to scroll up the list,
F2 -  o scroll down the list,
F3 -

to reinitialise all of the settings

(manufacturer's settings).

Press each setting to select or

change the parameters.

G -

Choose to adjust the contrast of the

display in relation to the ambient

light level (day, night or automatic).

H -

Choose to activate or deactivate

the traffi c information (TP).

213

A U D I O a n d T E L E M A T I C S

INFORMATION

A   - Consult the system information:
A1  -  the software version,
A2  -  the map data version,
A3 -

the system information database

version.

To update the versions, insert

the DVD containing the new data

and follow the instructions on the

screen.

B - Consult the GPS information:
B1 -

the satellite positions diagram

with the direction of movement of

the vehicle. Plus the position of

the satellite signal receivers,

B2 - the name of the current location,
B3 -

the longitude and latitude of the

current location,

B4 -

the position measurement status

(2D=3 satellites or fewer, 3D=4

satellites or more),

B5 -

the number of receiving satellites,

B6 -

to have north at the top of the map,

B7 -

to have the direction of the ve-

hicle at the top of the map,

B8 -

to pivot the map from overhead

or change the angle of the map.

System version, satellite

214

A U D I O a n d T E L E M A T I C S

Calendar, trip

D  -  Consult the driving information:
D1  -  the average speed,
D2  -  the average fuel consumption,
D3  -  the current fuel consumption,
D4 -

for speed and fuel consumption

graphs in 5 minute intervals,

D5 -

choose an automatic reinitiali-

sation (key at off for more than

4 hours) or manual reinitialisation

(press [Reset]),

D6 -

the distance which can still be

travelled (in relation to the fuel re-

maining and the recent average

consumption),

D7 -

the distance travelled since the

fuel tank was last fi lled (press

[Refuel] to reinitialise),

D8 -

the driving time (duration be-

tween the key being turned to on

then to off).

press [Start] to measure interme-

diate times with:

D9 - the duration,
D10 -  the distance,
D11 -  the speed,
D12 -  the fuel consumption.

C -

Make a note on the calendar of

special days, birthdays, ...

Use the arrows to fi nd a date and

press directly on the day required

to enter the event.

These double arrows permit

access to the driving infor-

mation screen, previous or

next.

D10

D11

D12

215

A U D I O a n d T E L E M A T I C S

F -

Consult the air conditioning con-

ditions:

F1  -  the fan speed indicator,
F2  -  the air selection indicator,
F3  -  the windscreen demisting indicator,
F4  -  the air conditioning indicator,
F5  -  the rear screen demisting indicator,
F6  -  the AUTO mode indicator.

E -

Consult the environment information:

E1 - the altitude,
E2 - the atmospheric pressure,
E3 -

the ambient temperature. The ice

symbol fl ashes if there is a risk

of ice.

G -

Make and receive telephone calls:

G1  -  enter the telephone number,
G2  -  delete a character,
G3  -  make the call.

Refer to the hands-free telephone

section to connect your Bluetooth

mobile telephone.

Environment, air conditioning,

telephone

216

A U D I O a n d T E L E M A T I C S

What is the Bluetooth® hands-free telephone with voice

recognition?

SPEAK
Pressing activates the voice recognition (“Listening” is displayed).
During voice recognition, a brief press pauses this recognition.
An extended press deactivates the recognition.
A brief press will activate the recognition even if a telephone call is

progress.

Audio system on/off.

PICK UP
Press to answer an incoming call.
If a second incoming call is received,

press this button to place the fi rst call on

hold and speak to the second caller.
In this case, a brief press switches be-

tween callers.
To establish a three-way conversation,

press the SPEAK button to switch to

voice recognition mode and say "In-

corporate the call".

HANG UP
Press to reject an incoming call.
During a call, pressing ends this call.

General notes

Decrease audio volume.

Increase audio volume.

HANDS-FREE TELEPHONE

You can make telephone calls using

a microphone, located in the courtesy

lamp making use of the steering mount-

ed controls or by the voice recognition

function using voice commands. Five

languages are available: English (by

default), Spanish, French, German and

Italian.

The system uses wireless communication technology referred to as

Bluetooth® which allows you to make hands-free telephone calls in

your vehicle via your Bluetooth® compatible mobile telephone.

217

A U D I O a n d T E L E M A T I C S

Changing the language,

programming the voice

Changing the language of the voice

commands
By default, the recognition system is in

English.

Programming the user's voice
You can use the user's voice program-

ming function to create a voice model

for one person per language.
The characteristics of your voice and

your pronunciation are recorded in this

model for improved voice recognition.
It is essential that the vehicle is parked

in a safe place, with the parking brake

applied.
Switch off your telephone during the

process to avoid any interruption.

1 - Press the SPEAK button.

5 - The system says the fi rst of 45 typical

phrases.

If you do not start the program-

ming process within approximately

3 minutes after pressing the SPEAK

button, the process is cancelled.
If you press the SPEAK button with-

in 5 seconds following the reading of

a voice command, the recording of

this command is repeated.

1 - Press the SPEAK button.

2 - Say "Setup".

3 - Say "Language".

5 - Say the language of your

choice in English, example:

say "French" for French.

7 - Say "Yes" to start the change

of language process or say

"No" to return to steps 4 to 7.

2 - Say "Word training".

4 - When you are ready to start,

press and hold the SPEAK

button.

6 - Repeat each phrase in the

table on the next page.

The system records your voice and

moves on to the recording of the next

command.
Continue the process until all of the

phrases have been recorded.

4 - The system says "Select a language:

English, Spanish, French, German or

Italian".

6 - The system then says "French se-

lected. Is this correct?"

8 - The system repeats the language

chosen and completes the change

of language process.

3 - An explanation message is given.

7 - After reading all the voice com-

mands, the system says "The word

enrolment is complete" and ends the

process.

218

A U D I O a n d T E L E M A T I C S

Training voice commands

# 790 (for # = "Hash")

* 671 (for * = "Star")

212 - 4 903

235 - 3 494

315 - 5 657

456 - 7 930

793 - 5 462

794 - 1 826

826 - 3 145

962 - 7 305

(531) 742 - 9 860

(632) 807 - 4 591

(800) 222 - 5015

(888) 555 - 1 212

0 123 456 789

55 66 77 88 99

44 33 22 11 00

Call 293 - 5804

Call * 350

Call 1 (234) 567 - 8 901

Dial 639 - 1542

Dial # 780

Dial (987) 654 - 3210

1058# 3794# Send

27643# 4321# Send

Cancel

Continue

Emergency number

Clear all

Help

Home, Work, Mobile, Pager

List of names

Phone book: Delete

Phone book: New entry

Phone book: Clear all

Redial

Repeat the training

40 Confi gure the confi rmation requests

Confi gure the language

Confi gure the matching options

Match a telephone

Transfer the call

Yes

219

A U D I O a n d T E L E M A T I C S

Matching your Bluetooth®

telephone

The system can register up to 7 Bluetooth®

compatible mobile telephones.
The telephone which has the highest

level of priority is connected automati-

cally.
It is absolutely essential that the vehicle

is parked in a safe place with the park-

ing brake applied.

1 - Press the SPEAK button.

7 - Say a 4-digit number which

will be recorded as the match-

ing code.

11 - When it detects a Bluetooth®

compatible mobile telephone,

the system says "Please say

the name of the telephone

after the bleep".

If the system does not detect the

Bluetooth® compatible mobile tele-

phone, the matching process stops

accompanied by an audible signal.
If you select a level of priority which

has already been allocated to an-

other telephone, the system asks

you if you wish to replace this level

of priority.

Remember this matching code as

you must enter it in the telephone

in one of the following steps of the

matching procedure.

9 - The system says "Start the matching

procedure on the telephone. Con-

sult the instructions in the telephone

manual".

2 - Say "Confi gure".

3 - Say "Matching options".

5 - Say "Match a telephone".

8 - The system confi rms the va-

lidity of the number spoken,

answer "Yes". Say "No" to re-

turn to step 7.

10 - Consult your mobile tele-

phone's user manual and

enter the matching code

recorded in step 7 in the

telephone.

12 - After the audible signal, allo-

cate a name to the telephone

by saying the name of your

choice.

13 - The system says "Allocate an order

of priority between 1 and 7. One is

the highest level of priority".

14 - Say a number between 1

and 7 to establish the level

of priority of the mobile tele-

phone.

15 - The system says and confi rms the

<name of the telephone> and the

<number> of its priority.

4 - The system says "Do you wish to

match a telephone, delete a tele-

phone or obtain the list of matched

telephones?".

6 - The systems says "Please say the

4 digits of a matching code".

If the code is incorrect, the system

locks. To clear the code:
- check that the telephone's voice

recognition is not activated,

- with the ignition on and the audio

system active, press the HANG UP

button for 2 seconds, 3 times in

succession.

16 - Answer "Yes" or say "No" to

return to step 13.

17 - The systems says "Matching

complete" then emits an audible

signal and deactivates the voice

recognition.

220

A U D I O a n d T E L E M A T I C S

Making a telephone call using a number, phone book

A Bluetooth® compatible mobile telephone

must be matched with the system.

Using a telephone number

If your vehicle is fi tted with the audio-

telematics screen, you can use the

press buttons to dial a number then

make a call.

Recording a name in the system's

phone book
The system has its own phone book,

independent of that of the mobile tele-

phone.
It can contain up to 32 names for each

language.
Each name in the phone book is asso-

ciated with 4 locations: HOME, WORK,

MOBILE and PAGER.

1 - Press the SPEAK button.

7 - The system says "HOME, WORK,

MOBILE OR PAGER".

2 - Day "Dial".

4 - Say the telephone number.

5 - The system asks you to con-

rm this number, answer

"Yes". Say "No" to return to

the previous step.

2 - Say "Phone book".

4 - Say "New entry".

6 - Say the name of your choice.

8 - Say the location which cor-

responds to the number that

you wish to record.

10 - Answer "Yes" or say "No" to

return to step 7.

12 - If you do not wish to change

the telephone number, re-

peat the original number to

retain it, otherwise say the

new number.

14 - Answer "Yes" or say "No" to

return to step 11.

1 - Press the SPEAK button.

3 - The system says "Number please".

3 - The system says "Select one of the

following items: New Entry, Change,

List of names, Delete or Clear all,

or say Cancel to return to the main

menu".

5 - The system says "Name please".

To enter a new number:

9 - The system asks you to confi rm the

location.

11 - If a telephone number has already

been recorded for this location, the

system says "The current number

is <number>, number please".

13 - The system asks you to confi rm the

number.

221

A U D I O a n d T E L E M A T I C S

Making a telephone call using a name in the phone book, receiving a call

Using a name in the system's

phone book
The name must be recorded in the sys-

tem's phone book.

8 - Answer "Yes" or say "No" to

return to step 4.

Redialling the last number

Receiving a call
The telephone ring is transmitted on the

speaker by the front passenger's seat.
If an audio source (CD, radio, ...) is in

operation when the call is received, it is

placed on mute and only the incoming

call is heard.
When the ignition switch is in the ACC

or ON position, the audio system is acti-

vated automatically if an incoming call

is received, even if it was originally off.

1 - Press the PICK UP button.

At the end of the call, the audio system

returns to its previous status.

1 - Press the SPEAK button.

2 - Say "Call".

4 - Say the name of the person

that you wish to call.

6 - Say the location correspond-

ing to the number that you

wish to call.

1 - Press the SPEAK button.

2 - Say "Redial".

3 - The system says "Name please".

5 - If several telephone numbers have

been recorded for this person, the

system says "Do you wish to call

<name> {home}, {work}, {mobile} or

{pager]?".

7 - The system request confi rmation of

the name.

9 - The system says "Call to <name> at

<location>" and makes the call.

222

A U D I O a n d T E L E M A T I C S

When the system is waiting for a voice command, say "Help" to obtain a list of commands which can be used in the current

situation.

Voice commands (1/2)

Press this button to start the voice recognition.

Confi gure

Phone book

Dial

Call

Redial

Emergency number

Matching options

Match a telephone

Delete a telephone

List of matched telephones

Select a telephone

Divert the call

Add a location

Confi gure the confi rmation requests

Language

New entry

Delete

Change

Call this number

Change another entry

Try again

Clear all

List of names

Home, at home

Work, at work

Mobile, on mobile

Pager, on pager

Help

Continue

All

Cancel

Mute

Deactivate mute

Yes

Content .. 12 13 14 15 ..
