Citroen C-Crosser (2012 year). Instruction - part 12

175

A U D I O a n d T E L E M A T I C S

Selecting changer mode

If the changer already

contains a disc, press the

"CD" button.
"CD", the disc and track

numbers and the playing time appear

in the screen.

After inserting at least one disc, printed

face upwards, the changer starts auto-

matically.

Ejecting a disc

Press this button briefl y to

remove the current disc

from the changer.

Once ejected, if the compact disc is

not removed within fi fteen seconds it

is re-loaded into the changer.

Loading a disc

Press the "LOAD" button

briefl y. "WAIT" appears on

the display.
When the changer is ready,

the indicator lamp on the "LOAD" button

comes on and "LOAD DISC N° (1-6)"

appears in the screen.
If several slots are empty, select one

using one of the "DISC" buttons.

The CD changer can hold up to 6 CDs.

Insert circular compact discs only.
8

cm compact discs cannot be

played by the changer.

Loading all of the discs

Ejecting all of the discs

Press this button for more

than two seconds. The cur-

rent disc is ejected.
Once this disc has been

removed, the next disc is ejected auto-

matically in its turn.
Repeat these steps until unloading is

complete.

Selecting a disc

Press one of the "DISC" but-

tons several times in suc-

cession until you reach the

disc required. The symbol

of the disc selected appears

in the screen.

See also "CD-Text display" and "MP3/

Tag ID3 CD".

Press the "LOAD" button for

more than two seconds.
The changer selects an

empty slot number from the

lowest to the highest and switches to

waiting for loading mode.
"LOAD DISC N° (1-6)" appears on the

display; insert the disc in the corre-

sponding slot.
The changer automatically selects the

next empty slot number and returns to

waiting for loading mode.
Repeat these steps until loading is

complete. Play begins with the last disc

inserted.

CD CHANGER

176

A U D I O a n d T E L E M A T I C S

Playing of the beginning of each track

Press the "SCAN" button

to start play of the fi rst ten

seconds of each track on

the disc. "SCAN" appears in

the screen and the corresponding track

number fl ashes.
To exit this mode, press this button

again.

On CD-R/RWs, the playback sound

quality depends on the encoding

software, the burning device and the

burning speed used.

Random playing on all of the discs

Press the "RDM" button for

more than two seconds to

start random playing of the

tracks on all of the discs.

"D-RDM" appears in the screen.
To exit this mode, press this button

again.

Fast search

Press and hold button " "

or " " to carry out a fast

backwards or forwards

search respectively.

Play begins when the button is re-

leased.

Selecting a track

Press button " " or " " to

select the previous track or

next track respectively.

Repeating a track

Press the "RPT" button to

repeat the playing of the cur-

rent track. "RPT" appears in

the screen.

To exit this mode, press this button

again.

Random playing of a disc

Press the "RDM" button to

start random playing of the

tracks on the disc. "RDM"

appears in the screen.

To exit this mode, press this button

again.

Repeating a disc

Press the "RPT" button for

more than two seconds to

repeat the playing of the

tracks of the current disc.

"D-RPT" appears in the screen.
To exit this mode, press this button

again.

Audio CD

177

A U D I O a n d T E L E M A T I C S

ERROR MESSAGES

If an error message appears on the screen, refer to the table below to fi nd out what it means and the solution to be applied

in order to rectify it.

TEXT

DESCRIPTION

SOLUTION

NO DISC

No disc present.
Disc not compatible.

Insert a disc.

ERROR 01

Disc inserted incorrectly.
Disc with condensation.

Insert the disc with the printed face upwards.
Clean the dampness off the disc.

ERROR 02

Disc dirty, scratched or distorted.
Excessive vehicle vibration.

Clean or replace the disc.
Try again when the vibration has stopped.

ERROR 03

Error on insertion or ejection.
Playing head misaligned.

Eject the disc and insert it again. If it is not ejected,

have the audio equipment checked.

ERROR HOT

Triggering of the internal protection against high

temperatures.

Wait approximately 30 minutes to allow the audio

system to cool.

ERROR

Communication error between the audio system

and the external system.
External system supply error.

Consult a CITROËN dealer.

178

A U D I O a n d T E L E M A T I C S

AUDIO: selection of Audio-video

(FM, CD, music server, ...) or Navi-

gation (map) display.

VOL: adjustment of audio-video

volume.

OPEN: tilts the screen

and permits access

to the CD/DVD. A

second press closes

the screen.

SCALE: changing the scale of the

map.

ENT: confi rms the choice of the

item selected on the screen.
For certain operations, confi rma-

tion is given by contact with the

touch screen.

Scrolling the map displayed or

selection of an item.

For safety reasons, the driver

must only carry out operations

which require prolonged atten-

tion with the vehicle stationary.

AUDIO-TELEMATIC SYSTEM

Changing the audio-video source

(FM, CD, music server, ...).

Mute on/off.
Next or previous selection for:
-

a radio station,

an audio track (CD),

a chapter (DVD).

Move a fi nger over the screen to operate

the system.
Use the buttons offered on the screen.

POWER: audio system on/off

(only).

Setting the audio volume.

179

A U D I O a n d T E L E M A T I C S

DESCRIPTION OF THE CONTROLS - MENUS

  MODE: Audio-video  menu for:
   -  radio,
  -

audio, MP3 or WMA CD,

- music

server,

- DVD.

MENU: Navigation-guidance menu

for selecting:
- a

destination,

a point of interest (POI),

an advanced search by POI,

one of the 20 previous destinations,

- an address stored in the ad-

dress book,

the return home,

certain navigation settings,

a route demonstration.

NAVI: display of the current location

on the map .

SET: Settings menu for:
-

switching off the screen,

selecting the sound setting,

selecting the picture quality,

selecting the language, the time

zone or the units,

- selecting the size of the DVD

picture,

- selecting the guidance voice,

the screen colour schemes or

display of the audio-video icon,

- setting certain equipment avail-

able in your vehicle.

INFO:

Information menu for the

consultation or adjustment of cer-

tain settings for your vehicle.

180

A U D I O a n d T E L E M A T I C S

NAVIGATION-GUIDANCE

What is the navigation system and

the GPS?
The satellite navigation system guides

the driver to the destination that he has

set in accordance with a chosen route.
Initially, it searches for the destination

required by the user, then it calculates

the route and fi nally it provides the vi-

sual and audible guidance instructions.

What precautions should be

observed in order to make best use

of the system?
Do not place anything on or near the

GPS aerial.
Do not use any digital communication

equipment (personal computers, etc.)

near the GPS aerial.
Do not affi x any refl ective fi lms or fi lms

containing carbon to the windows.

The GPS (Global Position-

ing System) consists of

several satellites distribut-

ed around the earth. They

continuously transmit digi-

tal signals which travel at the speed of

light, on 2 different frequencies.
At any given time, the system receives

its position in relation to the satellites

detected and the time of transmission

of the signal.
This enables the telematic unit to cal-

culate its position and therefore that of

the vehicle.
A repositioning process using the map

database stored on the hard disk allows

the vehicle to be positioned on the road

network, so improving the accuracy of

the vehicle location function.

What is a point of interest

(POI)?

Up to 40 different icons may

be displayed (refer to the

section "Points of interest

icon").
They are classifi ed

5 groups and identifi ed by one colour

for each group:
- Shops, fi

nance and businesses

(Green),

Vehicles and travel (Dark blue),

- Restaurants

(Orange),

- Public places and emergency ser-

vices (Brown),

Entertainment and attractions (Blue).

GPS

The system's measurements may be

inaccurate if the vehicle is:
-

in a tunnel or underground car park,

underneath a two-level motorway,

- in an area with several very high

buildings,

surrounded by closely planted trees.

Depending on the vehicle's situation

and the reception of the GPS informa-

tion, the displayed information may dis-

appear from the screen temporarily.

A point of interest (POI) is

represented by an icon on

the map, it represents an

airport, a station, a town

hall, ...

181

A U D I O a n d T E L E M A T I C S

A. Manoeuvre icon: indicates whether

the driver should turn left or right at

the next junction indicated by the

guidance and the distance to this

junction.

B. Guidance route: indicates the route

to the destination.

C. Vehicle marker: indicates the posi-

tion of the vehicle while driving.

D. TMC icon: displays traffi c infor-

mation such as traffi c jams, road

works, etc.

When the icon is touched, detailed

TMC information can be viewed.

E. Orientation mark: indicates the ori-

entation of the map displayed.

F. Map scale: indicates the scale of

the map displayed.

G. Name of the street: indicates the

name of the current street.

H. Direction frame: displays the num-

ber of the next road or the name

of the next street which the driver

should turn into.

I. Destination/intermediate destina-

tion icon: indicates the direction

of the destination or intermediate

destination.

Two-map display.

Single map display.

Information displayed on the

map during navigation

J. Destination/intermediate destination

information: indicates the distance

and the time remaining until the des-

tination or intermediate destination is

reached.

Press for access to the

Route

Menu in order to:

K1 - change the route in favour of

another making a detour through

a specifi ed region,

K2 - change the position of the desti-

nation, add an intermediate des-

tination and change the route

calculation conditions,

K3   - display a route by various methods,
K4   - delete a route created,
K5    -   search for points of interest (POI)

around the current location.

182

A U D I O a n d T E L E M A T I C S

B -

Select a location using the name of a

point of interest (POI).

Select:

B1 - the country,
B2 - the city,
B3 - the name of a stored POI,
B4 -

a POI category (airport, bowling alley,

bus station, car park, service station,

hotel, cinema, ...),

B5 - a detailed POI list.

C -

Select a location using an advanced

search based on a POI:

C1  -  around the current location,
C2  -  on the current route,
C3  -  in the vicinity of the destination,
C4  -  on a chosen street,
C5 -

along a motorway or in the vicinity of

the exit,

C6 - by scrolling the map,
C7 -

taking the point of departure of the current

route,

C8 -

specifying the latitude/longitude coordi-

nates.

A -

Select a location using the address or

street name of the destination. Select:

A1 - the country,
A2 - the city,
A3 - the street,
A4  -  the house number,
A5  -  the name of a junction,
A6 -

to select the search using either a number

or a junction.

You have a maximum of 100 points of interest (POI) within a radius

of approximately 60 miles (100 km).

Searching for a destination

using an address or points of

interest (POI)

183

A U D I O a n d T E L E M A T I C S

Searching using previous destinations, a stored address or a return home

E -

Select a location using an ad-

dress stored in the address book.

Sort by:

E1 - Icon,
E2 - Name,
E3 - Date.

D -

Select a location using one of the

20 previous destinations.

F - Select a return home directly.

Press YES to store your home

address (the fi rst time).

A U D I O a n d T E L E M A T I C S

Navigation settings and

information (1/2)

G -

Select the settings of functions

linked with the navigation to:

G1 - set the screen display parameters

such as:

- display 1 or 2 maps,

display or do not display the POIs

on the map, display selected icons,

- change the colours of the map,

display or do not display the name

of the current street.

display or do not display the ad-

dress of the current street.

G2 - set route conditions, such as,

- avoiding traffi c problems,

- avoiding selected areas,

- avoiding roads at a certain time.

G3 - set the route guidance mode and

the displaying of the results of the

route search,

G4 - save, change or delete a location

in the address book,

G5 - display and select the traffi c in-

formation such as traffi c jams or

road works by selecting dynamic

guidance.

A U D I O a n d T E L E M A T I C S

H -

Select basic information relating

to the navigation as well as a pre-

set route demonstration to:

H1 -

choose to divert your route to

avoid certain areas,

H2 -

select a location using an ad-

vanced search based on a POI

along a motorway or in the vicinity

of the motorway exit,

H3 - start/stop the demonstration,
H4 - recall a stored map screen.

Navigation settings and

information (2/2)

186

A U D I O a n d T E L E M A T I C S

Selecting points of interest (POI)

icons displayed on the map

You can select up to 40 types of point

of interest icon which are displayed on

your map screen.
Press the MENU button then [Navigation

Settings].

Press [Screen] then [Select] on the POI

line.
Press [4] which is displayed.

Press each POI required.
At each contact with a POI, the display

of [α] changes (α = the POI will be dis-

played on the screen).

General

Town centre
Locality

Shops, fi nance and businesses (Green)

Major companies
Shopping centre

Vehicles and travel (Dark blue)

CITROËN
Airport
Bus stop
Vehicle hire
Suburban station/station
Ferry terminal
Hotel
Park and ride
Car park (press +)
Service station
Rest area
Toll booth
Tourist information
Railway station

Restaurant (Orange)

Night life/night club
Restaurant

Public places and emergency

services (Brown)

Town Hall
Community centre
Convention/exhibition centre
Hospital
University/college

Entertainment and attractions (Blue)

Theme park
Bowling alley
Casino
Cinema
Golf course
Historical monument
Skating rink
Marina
Museum
Flying club
Leisure area
Ski station
Sports centre
Theatre/opera
Tourist attraction
Vineyard/wine and spirit store

187

A U D I O a n d T E L E M A T I C S

Press

Explanations

Result

Press the MENU button.

Press [Address/Junction].

Press [Country] and enter the name of the country using the touch keypad.
When a character of the name of the country is entered, if 5 countries

or fewer are recognised, you can select a country from a list which is

displayed or press [List].

You can select one of the 5 most recently selected countries by

pressing [Last 5] on the "Country" line.

Press [City] then [Keyword] and enter the name of the city using the touch

keypad.
When a character of the name of the city is entered, if 5 cities or fewer are

recognised, you can select a city from a list which is displayed or press

[List].

You can select a city using the post code.
Press [Post Code] and enter the number.

You can select one of the 5 most recently selected cities by

pressing [Last 5] on the "City" line.

Entering an address and starting guidance (1/2)

188

A U D I O a n d T E L E M A T I C S

Entering an address and starting guidance (2/2)

Press

Explanations

Result

Press [Street] and enter the name of a street using the touch keypad.
When a character of the name of the street is entered, if 5 streets or fewer

are recognised, you can select a street from a list which is displayed or

press [List].

Press [House #] and enter the number of the house using the touch

keypad.

You can enter the name of a junction instead of the number

of the street. Press [Junction] and select the name from a

list which is displayed.

This is the result once all of the information has been entered:

If you agree with the information press [Set], otherwise press one of the

buttons to correct.

Press [Start] to start the navigation.

189

A U D I O a n d T E L E M A T I C S

Press

Explanations

Result

Press [Route].

Press [Display new route].
The system offers a detour route (dynamic guidance).

Press [Back] and enter to return to the previous screen.
The system asks you to confi rm or not the new route.

Press [Yes] to confi rm your choice. The system displays the name of the

new route.
Press [No] to not register the route.

Traffic information

During navigation, the system gives you

traffi c information received in real time.
The system can then suggest a detour

route, if dynamic guidance has been

activated by pressing MENU, [Naviga-

tion settings] then [TMC].

190

A U D I O a n d T E L E M A T I C S

AUDIO-VIDEO

What is RDS?

RDS station following

Traffi c information function

Your radio automatically checks

and selects the best frequency

for the radio station to which it is

tuned (if the station broadcasts on sev-

eral transmitters or frequencies).
The frequency of a radio station covers

approximately 30 miles (50 km). The

change from one frequency to another

explains the loss of reception during a

journey.
If the station to which you are listening

does not have several frequencies in

the region in which you are currently lo-

cated, you can deactivate the automatic

frequency following.

Radio Data System (RDS) func-

tion on the FM waveband permits:

- tuning to the same station while

travelling through different regions

(if the transmitters of this station

cover the area through which you

are travelling),

- temporary tuning to traffi c informa-

tion announcements,

- display of the name of the station,

etc...

Most FM stations use RDS.
These stations transmit non-audible

data in addition to their programmes.
The data transmitted in this way allows

you access to various functions, mainly

displaying of the name of the station,

temporary tuning to traffi c information

announcements or automatic station

following.
RDS allows you to continue listening to the

same station by means of the frequency

following. However, in certain conditions,

this RDS frequency following cannot be

provided throughout the country. Radio

stations do not cover the whole country,

which explains the loss of reception of the

station during a journey.

The Traffic Program (TP) func-

tion permits automatic and

temporary switching to an FM

station broadcasting traffi c infor-

mation.

The radio station or the source that you

are listening to at this point is paused.
Once the traffi c information has ended,

the system switches back to the radio

station or the source that you were lis-

tening to initially.

Regional following mode

Some stations are organised in

a network.

In different regions, they broadcast dif-

ferent or shared programmes depend-

ing on the time of day.
You can follow:
-

a regional station only,

- the entire network, with the possibility

that you will be listening to a different

programme.

Programme types

Some stations offer the option

of listening to a themed type of

programme as a priority, select-

ed from the list available below:

NEWS, AFFAIRS, INFOS, SPORT,

EDUCATE, DRAMA, CULTURE,

SCIENCE, VARIED, POP M, ROCK M,

EASY M, LIGHT M, CLASSICS, OTHER

M, WEATHER, FINANCE, CHILDREN,

SOCIAL, RELIGION, PHONE IN, TRAVEL,

LEISURE, JAZZ, COUNTRY, NATION M,

OLDIES, FOLK M, DOCUMENT.

Content .. 10 11 12 13 ..
