Chrysler 300/300 Touring/300C, Dodge Magnum. Manual - part 818

6. Install lower liftgate trim panel (Refer to 23 - BODY/DECKLID/HATCH/LIFTGATE/TAILGATE/TRIM PANEL -

INSTALLATION).

7. Install the rear wiper arm (Refer to 8 - ELECTRI-

CAL/WIPERS/WASHERS/WIPER ARMS - INSTAL-
LATION). Torque nut to 18 N·m (13 ft. lbs.).

8. Connect the battery negative cable.

8R - 92

WIPERS/WASHERS - SERVICE INFORMATION

WASHER FLUID LEVEL SWITCH

REMOVAL

1. Disconnect and isolate the battery negative cable.

2. Drain washer fluid from the reservoir and into a

suitable clean container. This can be done by dis-
connecting the windshield washer hose from the
front (outboard) washer pump and allowing the
washer fluid to drain into a container through a
temporary jumper hose connected to the front
washer pump.

3. Remove the washer reservoir (Refer to 8 - ELEC-

TRICAL/WIPERS/WASHERS/WASHER

RESER-

VOIR - REMOVAL).

4. Remove the washer fluid level switch by pulling out

of reservoir. Inspect the grommet and if installing a
new switch, always use a new grommet.

WIPERS/WASHERS - SERVICE INFORMATION

8R - 93

INSTALLATION

1. Inspect grommet and if installing new switch, use a

new grommet. Position the switch into opening and
firmly press into place.

2. Install the washer reservoir (Refer to 8 - ELECTRI-

CAL/WIPERS/WASHERS/WASHER RESERVOIR -
INSTALLATION).

3. Refill the reservoir with fluid drained previously.

4. Connect the battery negative cable.

8R - 94

WIPERS/WASHERS - SERVICE INFORMATION

WASHER PUMP MOTOR

REMOVAL

1. Disconnect and isolate the battery negative cable.

2. Drain washer fluid from the reservoir and into a

3. Remove the washer reservoir (Refer to 8 - ELEC-

TRICAL/WIPERS/WASHERS/WASHER

RESER-

VOIR - REMOVAL).

4. Remove the washer pump motor by pulling out of

reservoir. Inspect the grommet and if installing a
new motor, always use a new grommet.

WIPERS/WASHERS - SERVICE INFORMATION

8R - 95
