3. (Z911) GROUND CIRCUIT OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z911) Does the test light illuminate brightly? Yes >> Go To 4 No >> Repair the (Z911) ground circuit for an open. Perform the OCS VERIFICATION TEST-VER 1. 4. (F201) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN OR SHORTED Turn the ignition on. Using a 12-volt test light connected to ground, check the (F201) Fused Does the test light illuminate brightly? Yes >> Go To 5 No >> Repair the (F201) Fused Ignition Switch Output circuit for an open or short. Perform the OCS VERIFICATION TEST-VER 1. 8E - 202 ELECTRONIC CONTROL MODULES - ELECTRICAL DIAGNOSTICS LX |
