FLEX PLATE REMOVAL 1. Remove the transmission. (Refer to 21 - TRANS- MISSION/TRANSAXLE/AUTOMATIC - NAG1 - REMOVAL). 2. Remove the bolts and flexplate (1). INSTALLATION 1. Position the flexplate or flywheel onto the crank- shaft and install the bolts hand tight. 2. For automatic transmissions: Tighten the flex- plate retaining bolts to 95 N·m (70 ft. lbs.). 3. Install the transmission. (Refer to 21 - TRANSMISSION/TRANSAXLE/AUTOMATIC - NAG1 - INSTALLATION). 9 - 2380 ENGINE - 5.7L SERVICE INFORMATION LX |
