P0563-ECM VOLTAGE TOO HIGH For a complete wiring diagram Refer to Section 8W • When Monitored: • Set Condition: Possible Causes CHECKING ECM POWER AND GROUNDS ECM INTERMITTENT CONDITION Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to 9 - ENGINE - Diagnostic Test 1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, erase ECM DTCs. NOTE: This DTC may be caused by a charging system problem. Refer to the Service Information and verify Turn the ignition on. With the scan tool, read ECM DTCs. Did this DTC set again? Yes >> Go To 2 No >> Go To 3 2. CHECK POWER AND GROUNDS Refer to the symptom list and perform the Checking the ECM Power and Ground test. Were any problem found with the ECM powers and grounds? Yes >> Repair as necessary. Perform the ECM Verification Test Ver. 1. (Refer to 9 - ENGINE - DIAGNOSIS AND TESTING) No >> Replace and program the Engine Control Module in accordance with the Service Information. Perform the ECM Verification Test Ver. 1. (Refer to 9 - ENGINE - DIAGNOSIS AND TESTING) 3. INTERMITTENT CONDITION WARNING: WHEN THE ENGINE IS OPERATING, DO NOT STAND IN A DIRECT LINE WITH THE FAN. DO NOT NOTE: The conditions that set the DTC are not present at this time. The following list may help in identi- Review the DTC When Monitored and Set Conditions. If possible, try to duplicate the conditions under which the Refer to any Technical Service Bulletins (TSB) that may apply. Visually inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. 9 - 1492 ENGINE ELECTRICAL DIAGNOSTICS - DIESEL LX |
