9. TP SENSOR SIGNAL CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (K22) and (K122) TP Is the resistance above 100k ohms for each circuit? Yes >> Go To 10 No >> Repair the short to ground in the (K22) or (K122) TP Sen- sor Signal circuit. Perform the POWERTRAIN VERIFICATION TEST. (Refer 9 - 856 ENGINE ELECTRICAL DIAGNOSTICS LX |
