NOTE: Prior to using Special Tool 9361, lubricate 7. Place NEW knuckle sleeve (2) onto Installer Bolt 9361-12 (1), and slide it up to Bolt’s head. 8. Starting from knuckle forward end, slide Bolt 9361-12 (1) with sleeve (5) through knuckle (2) and 9. Install Installation Thrust Bearing (around 3/8 inch thick) and special flange nut (4) on end of Bolt. 10. While holding Bolt head (1) stationary, rotate Nut (4) (using hand tools) installing sleeve in knuckle. 11. Remove special tool. 12. Install spring link-to-knuckle bolt (2) front-to-rear through knuckle and link, then install nut. While 13. Remove under-hoist utility jack or jack stand from under spring link. 2 - 118 REAR LX |
