Fig. 149: Removing 1-2-3-4 Clutch Piston 1-2-3-4 Clutch Piston Removal Callout Component Name 1-2-3-4 Clutch Piston Dam Retaining Ring. NOTE: Use care when compressing the 1-2-3-4 clutch spring
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
3-5 REVERSE CLUTCH PISTON REMOVAL 1 too much may damage it. NOTE: Refer to Retaining Ring Reuse Notice . 2 1-2-3-4 Clutch Piston Dam Assembly 3 1-2-3-4 Clutch Spring 4 1-2-3-4 Clutch Piston It may be necessary to apply air to the apply After air is applied, it may be necessary to
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 150: Removing 3-5 Reverse Clutch Piston 3-5 Reverse Clutch Piston Removal Callout Component Name Preliminary Procedure 1. Install the 1-2-3-4 and 3-5 reverse clutch housing assembly onto the torque converter (with fluid pump) housing assembly. 2. Apply hand pressure on the 1-2-3-4 clutch piston housing while applying compressed
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1-2-3-4 AND 3-5 REVERSE CLUTCH PISTON SEALS REPLACEMENT air to the apply passage in order to unseat the 3-5 reverse clutch piston. 1 1-2-3-4 Clutch Piston Housing Retaining Ring NOTE: Refer to Retaining Ring Reuse Notice . 2 1-2-3-4 Clutch Piston Housing 3 3-5 Reverse Clutch Spring 4 3-5 Reverse Clutch Piston
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
|
|
