Fig. 27: View Of Oil Level Indicator Tube & Transmission Seal
Courtesy of GENERAL MOTORS CORP.
1. Install a NEW seal (2) to the indicator tube.
2. Install the oil level indicator tube (1).
3. Install the transmission. Refer to Transmission Replacement.
4. Lower the vehicle.
5. Check the transmission fluid level. Refer to Transmission Fluid Check.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 28: View Of Transmission Oil Level Indicator
Courtesy of GENERAL MOTORS CORP.
6. Install the transmission oil level indicator.
7. Lock the transmission oil level indicator.
RANGE SELECTOR LEVER CABLE REPLACEMENT
REMOVAL PROCEDURE
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 29: View Of Steering Cable Retainer On Steering Column
Courtesy of GENERAL MOTORS CORP.
1. Position the steering column shift lever to the park position.
2. Remove the instrument panel knee bolster. Refer to Knee Bolster Replacement (with
RPO SLT) or Knee Bolster Replacement (without RPO SLT) .
3. Remove the driver seat. Refer to Front Seat Replacement - Bucket .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
4. Pull back the carpet and insulation around the driver area.
5. Remove the retainer securing the cable to the steering column.
Fig. 30: View Of Cable, Steering Column Ball Stud & Steering Column Bracket
Courtesy of GENERAL MOTORS CORP.
6. Remove the cable end from the steering column ball stud.
7. Depress the tangs and remove the cable from the steering column bracket.
