Fig. 76: View Of Water Outlet Bolts
Courtesy of GENERAL MOTORS CORP.
13. Install the water outlet bolts.
Tighten: Tighten the water outlet bolts to 25 N.m (18 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 77: View Of Electrical Harness Bracket Bolt
Courtesy of GENERAL MOTORS CORP.
14. Install the electrical harness bracket.
15. Install the electrical harness bracket bolt.
Tighten: Tighten the electrical harness bracket bolt to 10 N.m (89 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 78: View Of Turbocharger Inlet Coolant Hose At Turbocharger Coolant Bypass
Courtesy of GENERAL MOTORS CORP.
16. Connect the turbocharger coolant inlet hose.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 79: View Of Main Electrical Connector Harness Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
17. Install the main electrical harness bracket.
18. Install the main electrical harness bracket bolts.
Tighten: Tighten the main electrical harness bracket bolts to 10 N.m (89 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
