Fig. 79: View Of Air Inlet Tube
Courtesy of GENERAL MOTORS CORP.
5. Remove the air inlet tube nuts.
6. Remove the air inlet tube.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 80: View Of EGR Cooler
Courtesy of GENERAL MOTORS CORP.
7. Remove the rear EGR cooler bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 81: View Of EGR Mount Bolt
Courtesy of GENERAL MOTORS CORP.
8. Remove the EGR mount bolt.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
