Chevrolet Silverado / GMC Sierra. Manual - part 530
Fig. 7: View Of Exhaust Outlet Clamp
Courtesy of GENERAL MOTORS CORP.
4. Loosen the exhaust outlet holding clamp.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 8: View Of Exhaust Outlet
Courtesy of GENERAL MOTORS CORP.
5. Remove the exhaust outlet.
EXHAUST PIPE REMOVAL - LEFT SIDE
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 9: View Of Left Exhaust Pipe Heat Shield & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Remove the left exhaust pipe heat shield bolts.
2. Remove the left exhaust pipe heat shield.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 10: Left Exhaust Pipe Bolts Removal Sequence
Courtesy of GENERAL MOTORS CORP.
3. Remove the exhaust pipe bolts in the proper sequence.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
