Fig. 361: View Of Turbocharger Exhaust Pipe & Clamp
Courtesy of GENERAL MOTORS CORP.
71. Raise the vehicle. Refer to Lifting and Jacking the Vehicle .
72. Drain the engine oil.
73. Remove the exhaust pipe to the exhaust outlet clamp. Move the clamp onto the exhaust pipe.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
74. If vehicle is 4-wheel drive (4WD) remove the lower oil pan. Refer to Lower Oil Pan
Replacement.
Fig. 362: View Of Torque Convertor Bolt
Courtesy of GENERAL MOTORS CORP.
75. If equipped with an automatic transmission, mark the flywheel and torque converter
relationship for assembly purposes.
76. Remove the torque convertor bolts through the starter opening.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 363: View Of Transmission Oil Cooler Lines, Bracket & Bolt
Courtesy of GENERAL MOTORS CORP.
77. If equipped with an automatic transmission, remove the transmission oil line clip nut.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 364: View Of Fill Tube To Bellhousing Nuts
Courtesy of GENERAL MOTORS CORP.
78. If equipped with an automatic transmission, remove the nuts retaining transmission fluid fill
tube bracket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
